Hose Installation - Webasto Sprinter Vancouver Standard Manual

Item No. Part Number
21 5011043B
22 5011195B
24 5011002B
11 5013213A
18 5013071A
25 5011005B
12 5013167A
27 62A031060A
28 5013074A
23 5011045B
38 629069011A
NOTE: If you are unsure about how to crimp Burgaflex hose fittings, refer
to the instructions on the next two pages for more information.

Hose Installation

Description
FITTING REFRIG STR -06THD TO -06H
FITTING REFRIG STR-06MTHD TO -06H
FITTING REFRIGERANT 90 -6CONN -6HOSE
HOSE REFRIGERANT SIZE -6 X 11M LONG
BAG - TXV PLATE
FITTING REFRIGERANT 90 -12THD -10HOSE
HOSE REFRIGERANT SIZE -10 X 11 METERS
TIE-IN ADAPTER
BAG - WASHERS SLIMLINE
FITTING REFRIGERANTSTR -10THD -10HOSE
TEE DRAIN HOSE 12MM OD
22
Sprinter
Quantity
2
1
1
As needed
1
1
As needed
1
1
1
1
