328 STARTING AND OPERATING
All trailer hitches should be professionally installed on
your vehicle.

Trailer Towing Weights (Maximum Trailer Weight Ratings)

The following chart provides the maximum trailer weight ratings towable for your given drivetrain.
Engine Model
3.7L 4x2
3.7L 4x4
5.7L 4x2
5.7L 4x4
GCWR (Gross Com-
bined Wt. Rating)
8,700 lbs (3 946 kg)
8,800 lbs (3 991 kg)
12,700 lbs (5 760 kg)
12,700 lbs (5 760 kg)
Refer to local laws for maximum trailer towing speeds.
Frontal Area Max. GTW (Gross
Trailer Wt.)
40 sq ft 3,500 lbs (1 587 kg)
(3.72 sq m)
40 sq ft 3,500 lbs (1 587 kg)
(3.72 sq m)
60 sq ft 7,400 lbs (3 356 kg)
(5.57 sq m)
60 sq ft 7,200 lbs (3 266 kg)
(5.57 sq m)
Max. Trailer
Tongue Wt. (See
Note)
350 lbs (159 kg)
350 lbs (159 kg)
740 lbs (336 kg)
720 lbs (327 kg)
