Summary of Contents for Jeep COMMANDER 2010
-
Page 3: Table Of Contents
INTRODUCTION/WELCOME WELCOME FROM CHRYSLER GROUP LLC ..2 CONTROLS AT A GLANCE DRIVER COCKPIT ....4 INSTRUMENT CLUSTER ..6 GETTING STARTED KEY FOB . -
Page 4: Introduction/Welcome
INTRODUCTION/WELCOME WELCOME FROM CHRYSLER GROUP LLC Congratulations on selecting your new Chrysler Group LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles. IMPORTANT: This User Guide is intended to familiarize you with the important features of your vehicle. -
Page 5: Rollover Warning
Never park your vehicle over dry grass or other combustible materials. The heat from your vehicle exhaust system could cause a fire. CHRYSLER, DODGE, JEEP, ATF+4, MOPAR and uconnect are registered trademarks of Chrysler Group LLC. COPYRIGHT ©2009 CHRYSLER GROUP LLC... -
Page 6: Controls At A Glance
CONTROLS AT A GLANCE DRIVER COCKPIT... - Page 7 CONTROLS AT A GLANCE...
-
Page 8: Instrument Cluster
CONTROLS AT A GLANCE INSTRUMENT CLUSTER Warning Lights - Low Fuel Warning Light - Charging System Light** - Oil Pressure Warning Light** - Anti-Lock Brake (ABS) Light** - Airbag Warning Light** - Electronic Throttle Control (ETC) Light - Tire Pressure Monitoring System (TPMS) Light - Seat Belt Reminder Light - Brake Warning Light** - Malfunction Indicator Light (MIL)**... - Page 9 CONTROLS AT A GLANCE Indicators - Turn Signal Indicators - High Beam Indicator - Front Fog Light Indicator - Vehicle Security Indicator* - TOW/HAUL Indicator - 4WD LOW Indicator - Electronic Stability Program (ESP) Indicator Light/Traction Control System (TCS) Indicator - Cruise Indicator * If equipped ** Bulb Check with Key On...
-
Page 10: Getting Started
GETTING STARTED KEY FOB Leaving unattended children in a vehicle is dangerous for a number of reasons. A child or others could be injured. Children should be warned not to touch the parking brake, brake pedal, or the shift lever. Do not leave the key in the ignition. A child could operate power windows, other controls, or move the vehicle. -
Page 11: Theft Alarm
• Do not start or run an engine in a closed garage or confined area. Exhaust gas contains Carbon Monoxide (CO) which is odorless and colorless. Carbon Monoxide is poisonous and can cause serious injury or death when inhaled. • Keep Key Fob transmitters away from children. Operation of the Remote Start System, windows, door locks or other controls could cause serious injury or death. -
Page 12: Front Seats
GETTING STARTED FRONT SEATS Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Only adjust a seat while the vehicle is parked. Manual Seat Adjustment Forward/Rearward •... -
Page 13: Heated Seats
Eight-Way Driver Power Seat Four-Way Passenger Power Seat DO NOT place any article under a power seat or impede its ability to move as it may cause damage to the seat controls. Seat travel may become limited if movement is stopped by an obstruction in the seat’s path. -
Page 14: Memory Seats
GETTING STARTED • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion or other physical condition must exercise care when using the seat heater. It may cause burns even at low temperatures, especially if used for long periods of time. -
Page 15: Rear Seats
REAR SEATS 40/20/40 Second Row Folding Seat Do not drive the vehicle with the outer second row seats in the tumbled position. The outer second row seats are only intended to be tumbled for entry and exit to the third row seat. - Page 16 GETTING STARTED 50/50 Third Row Folding Seat 2nd Row Heated Seats • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion or other physical condition must exercise care when using the seat heater. It may cause burns even at low temperatures, especially if used for long periods of time.
-
Page 17: Tilt/Telescoping Steering Column
• Do not place anything on the seat that insulates against heat, such as a blanket or cushion. This may cause the seat heater to overheat. Sitting in a seat that has been overheated could cause serious burns due to the increased surface temperature of the seat. -
Page 18: Adjustable Pedals
GETTING STARTED ADJUSTABLE PEDALS Do not adjust the pedals while the vehicle is moving. You could lose control and have an accident. Always adjust the pedals while the vehicle is parked. Do not place any article under the adjustable pedals or impede its ability to move, as it may cause damage to the pedal controls. -
Page 19: Operating Your Vehicle
OPERATING YOUR VEHICLE TURN SIGNAL/LIGHTS LEVER Headlights/Parking Lights • Rotate the end of the lever to the first detent for parking lights for headlights and the third detent for AUTO. • When set to AUTO, the system automatically turns the headlights on or off based on ambient light levels. -
Page 20: Wiper/Washer Lever
OPERATING YOUR VEHICLE Fog Lights • Turn on the parking lights or low beam headlights and pull out the end of the lever. Turn Signals/Lane Change Assist • Tap the lever up or down once and the turn signal (right or left) will flash three times and automatically turn off. -
Page 21: Speed Control Lever
OPERATING YOUR VEHICLE SPEED CONTROL LEVER Leaving the Electronic Speed Control system on when not in use is dangerous. You could accidentally set the system or cause it to go faster than you want. You could lose control and have an accident. Always leave the Electronic Speed Control system off when you are not using it. -
Page 22: Electronic Range Select (Ers)
OPERATING YOUR VEHICLE ELECTRONIC RANGE SELECT (ERS) MANUAL CLIMATE CONTROLS Air Recirculation • Use recirculation for maximum A/C operation. • For window defogging, turn the recirculation button off. • Recirculation is not allowed in defrost, floor, defrost/floor (mix) modes. • The Electronic Range Select (ERS) feature allows you to select the desired top gear. -
Page 23: Automatic Temperature Controls (Atc)
OPERATING YOUR VEHICLE AUTOMATIC TEMPERATURE CONTROLS (ATC) Automatic Operation • Turn the Mode Control to the AUTO position and the Blower Control to either LO AUTO or HIGH AUTO position. • Select the desired temperature by rotating the temperature controls for the driver or passenger. -
Page 24: Parksense® Rear Park Assist
OPERATING YOUR VEHICLE Rear Climate Control • The Manual Rear Climate Control system has one floor air outlet (passenger side), and two panel outlets in the rear quarter trim (on each side). The unit provides warm or cool air through the floor and upper outlets. •... -
Page 25: Power Liftgate
OPERATING YOUR VEHICLE POWER LIFTGATE • The power liftgate may be opened manually or by pressing the LIFTGATE button on the Key Fob. Press the LIFTGATE button on the Key Fob twice within five seconds to open the power liftgate. Once the liftgate is open, pressing the button twice within five seconds a second time will close the liftgate. -
Page 26: Wind Buffeting
OPERATING YOUR VEHICLE Opening Sunroof Express • Press the switch rearward and release. The sunroof will fully open and stop automatically. Closing Sunroof Express • Press the switch forward and release. The sunroof will close automatically from any position. Manual Open/Close •... -
Page 27: Electronics
ELECTRONICS NON-TOUCH-SCREEN RADIOS RES Radio RES/RSC Radio... -
Page 28: Audio Settings
ELECTRONICS NOTE: uconnect™ phone and Voice Recognition are vehicle options which must be ordered separately. The buttons on the radio will only be active if the vehicle has been equipped with the option. • The radio sales code is located on the lower right side of the radio faceplate. •... -
Page 29: Touch-Screen Radios
ELECTRONICS TOUCH-SCREEN RADIOS Navigation Radio – RER Multimedia Radio – REN... -
Page 30: Radio Mode
ELECTRONICS NOTE: uconnect™ phone and Voice Recognition are vehicle options which must be ordered separately. The buttons on the radio will only be active if the vehicle has been equipped with the option. • The radio sales code is located on the lower right side of the radio faceplate. •... - Page 31 Hard Disc Drive Operation Copy Complete Audio Disc To Hard-Drive • Press the OPEN/CLOSE hard-key and insert a disc, then press the MENU hard-key. • Touch the MY FILES soft-key, then select MY MUSIC. • Touch the IMPORT MUSIC soft-key, then touch the FROM DISC soft-key in the next screen to start the process.
- Page 32 ELECTRONICS • For software updates, visit http://www.chrysler.com/en/owners/mygig/ website, visit http://www.navteq.com website, or contact your authorized dealer for the latest available software. NOTE: Many features of this radio are speed dependent. For your own safety, it is not possible to use the touch-screen keyboard to enter a name (e.g., street name) while the vehicle is in motion.
-
Page 33: Remote Audio Controls
REMOTE AUDIO CONTROLS VIDEO ENTERTAINMENT SYSTEM (VES)™ • To use the headphones, press the power button located on the right ear cup. Select the channel on the headphones (1or2) that corresponds to the channel selected on the VES™ screen. ELECTRONICS •... - Page 34 ELECTRONICS Operation Of The Touch-Screen Radio • To view a DVD video press the OPEN/CLOSE hard-key and insert the disc. Playback will begin automatically after the DVD is recognized by the disc drive. If playback does not begin automatically follow these steps: •...
-
Page 35: Electronic Vehicle Information Center (Evic)
ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) • Press the STEP button to scroll through sub menus (i.e., Trip Functions, Avg. Fuel Economy, DTE, Elapsed Time, and Units). • Press and release the Compass/Temperature Compass/Temperature screens. • Press the RESET button to RESET Trip Functions and change Personal Settings. UNIVERSAL GARAGE DOOR OPENER •... -
Page 36: Power Inverter
ELECTRONICS Programming A Rolling Code System • At the garage door opener motor (in the garage), locate the “learn” or “training” button. This can usually be found where the hanging antenna wire is attached to the garage door opener motor (it is NOT the button normally used to open and close the door). •... -
Page 37: Power Outlet
To Avoid Serious Injury or Death: Do not use a three-prong adaptor. Do not insert any objects into the receptacles. Do not touch with wet hands. Close the lid when not in use. If this outlet is mishandled, it may cause an electric shock and failure. POWER OUTLET •... -
Page 38: Making A Phone Call
ELECTRONICS Phone Pairing NOTE: Pairing is a one-time initial setup before using the phone. You will also need to follow the Bluetooth instructions in your cell phone user guide to complete the phone pairing setup. • Press the Phone button •... -
Page 39: Voice Recognition
Changing The Volume • Start a dialogue by pressing the Phone button normal call. • Use the radio ON/OFF VOLUME rotary knob to adjust the volume to a comfortable level while the uconnect™ system is speaking. Please note the volume setting for uconnect™ is different than the audio system. -
Page 40: Off-Road Capabilities
OFF-ROAD CAPABILITIES FOUR-WHEEL DRIVE OPERATION ® Quadra-Trac I Operating Instructions/Precautions ® • The Quadra-Trac I is a single-speed (HI range only) transfer case, which provides convenient full-time four–wheel drive. No driver interaction is required. The Brake Traction Control (BTC) System, which combines standard ABS and Traction Control, provides resistance to any wheel that is slipping to allow additional torque... -
Page 41: Shifting Procedures
OFF-ROAD CAPABILITIES Shifting Procedures 4WD HI To 4WD LOW • With the vehicle at speeds of 0 to 3 mph (0 to 5 km/h), key ON or engine running, shift the transmission into NEUTRAL, and raise the transfer case T-handle. The “4WD LOW” indicator light in the instrument cluster will begin to flash and remain on solid when the shift is complete. -
Page 42: Utility
UTILITY INTERIOR STORAGE COMPARTMENTS Rear Storage Compartment • The cargo tie-downs, located on the cargo area floor, should be used to safely secure loads when the vehicle is moving. WARNING! • To help protect against personal injury, passengers should not be seated in the rear cargo area. -
Page 43: Trailer Towing Weights (Maximum Trailer Weight Ratings)
UTILITY... -
Page 44: Recreational Towing (Behind Motorhome, Etc.)
UTILITY RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing - Two-Wheel Drive Models • Recreational towing is allowed ONLY if the driveshaft is removed. Towing with the rear wheels on the ground while the driveshaft is connected can result in severe transmission damage. WARNING! If the driveshaft is removed, the vehicle can roll even if the... -
Page 45: Brake/Transmission Interlock Manual Override
BRAKE/TRANSMISSION INTERLOCK MANUAL OVERRIDE • The manual override may be used in the event that the shift lever should fail to move from PARK with the Key Fob in the ON position and the brake pedal pressed. • To operate the shift lock manual override, perform the following steps: •... -
Page 46: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES 24 HOUR TOWING ASSISTANCE • Dial toll-free 1-800-521-2779. • Provide your name, vehicle identification number and license plate number. • Provide your location, including telephone number, from which you are calling. • Briefly describe the nature of the problem and answer a few simple questions. •... -
Page 47: Charging System Light
WHAT TO DO IN EMERGENCIES Driving a vehicle with the red brake light on is dangerous. Part of the brake system may have failed. It will take longer to stop the vehicle. You could have an accident. Have the vehicle checked immediately. - Malfunction Indicator Light (MIL) •... -
Page 48: Airbag Warning Light
WHAT TO DO IN EMERGENCIES - Electronic Throttle Control (ETC) Light • This light informs you of a problem with the Electronic Throttle Control (ETC) system. • If a problem is detected, the light will come on while the engine is running. Cycle the ignition key when the vehicle has completely stopped and the shift lever is placed in the PARK position;... -
Page 49: If Your Engine Overheats
WHAT TO DO IN EMERGENCIES IF YOUR ENGINE OVERHEATS • In any of the following situations, you can reduce the potential for overheating by taking the appropriate action. • On the highways — slow down. • In city traffic — while stopped, shift transmission into NEUTRAL, but do not increase engine idle speed. -
Page 50: Jacking And Tire Changing
WHAT TO DO IN EMERGENCIES JACKING AND TIRE CHANGING • Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel. -
Page 51: Spare Tire Stowage
WHAT TO DO IN EMERGENCIES Spare Tire Stowage • To remove or stow the spare, use the jack handle to rotate the “spare tire drive” nut which is located under a plastic cover under the cargo load floor, just inside the liftgate opening. •... - Page 52 WHAT TO DO IN EMERGENCIES • Place the jack: • For front wheels, place it under the front lower control arm. • For rear wheels, place it under the axle near the wheel to be changed. • Turn the jack screw clockwise to firmly engage the jack saddle with the lift area of the sill flange.
-
Page 53: Jump-Starting
WHAT TO DO IN EMERGENCIES JUMP-STARTING Any procedure other than the following could result in: • Personal injury caused by electrolyte squirting out the battery vent, • Personal injury or property damage due to battery explosion, • Damage to the charging system of the booster vehicle or of the immobilized vehicle. - Page 54 WHAT TO DO IN EMERGENCIES • A battery generates hydrogen gas which is flammable and explosive. Keep flames or sparks away from the battery vent holes. Don’t lean over the battery when attaching clamps or allow the clamps to touch each other. •...
-
Page 55: Emergency Tow Hooks
WHAT TO DO IN EMERGENCIES EMERGENCY TOW HOOKS • If your vehicle is equipped with tow hooks, they are mounted in the front and the rear. NOTE: For off-road recovery, it is recommended to use both of the front tow hooks to minimize the risk of damage to the vehicle. -
Page 56: Towing A Disabled Vehicle
WHAT TO DO IN EMERGENCIES... -
Page 57: Event Data Recorder (Edr)
WHAT TO DO IN EMERGENCIES EVENT DATA RECORDER (EDR) • This vehicle is equipped with an Event Data Recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle's systems performed. -
Page 58: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE OPENING THE HOOD • Pull the hood release lever located below the steering wheel at the base of the instrument panel. • Reach into the opening beneath the center of the hood and move the safety latch lever while lifting the hood at the same time. -
Page 59: Engine Compartment
MAINTAINING YOUR VEHICLE... - Page 60 MAINTAINING YOUR VEHICLE...
-
Page 61: Fluids And Capacities
MAINTAINING YOUR VEHICLE FLUIDS AND CAPACITIES Component Fluid, Lubricant, or Genuine Part Engine Coolant - MOPAR 3.7L without rear /100,000 Mile Formula HOAT (Hybrid Organic heat. Additive Technology) or equivalent. Engine Coolant - MOPAR 3.7L with rear heat. /100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) or equivalent. -
Page 62: Maintenance Chart
MAINTAINING YOUR VEHICLE... -
Page 63: Maintenance Record
MAINTAINING YOUR VEHICLE Maintenance Record Odometer Date Signature, Authorized Service Center 6,000 Miles (10,000 km) or 6 Months 12,000 Miles (20,000 km) or 12 Months 18,000 Miles (30,000 km) or 18 Months 24,000 Miles (40,000 km) or 24 Months 30,000 Miles (50,000 km) or 30 Months 36,000 Miles... -
Page 64: Fuses
MAINTAINING YOUR VEHICLE FUSES Underhood Fuses (Integrated Power Module) - Page 65 MAINTAINING YOUR VEHICLE • The Integrated Power Module (IPM) is located in the engine compartment near the battery. This center contains cartridge fuses, mini-fuses and relays. Cavity Cartridge Fuse 30 Amp Pink 50 Amp Red Mini-Fuse 10 Amp Red Lt Park Lamps 10 Amp Red Trailer-Tow Park Lamps 10 Amp Red...
- Page 66 MAINTAINING YOUR VEHICLE Underhood Fuses (Power Distribution Center) • The Power Distribution Center (PDC) is located in the left side of the engine compartment near the Brake Fluid Reservoir. This center contains cartridge fuses, mini-fuses and relays. Cavity Cartridge Fuse 50 Amp Red 40 Amp Green 50 Amp Red...
- Page 67 MAINTAINING YOUR VEHICLE Cavity Cartridge Fuse 30 Amp Pink 40 Amp Green 40 Amp Green 30 Amp Pink Mini-Fuse ABS Pump Accessory Delay, Seats JB Power Wiper Motor 20 Amp Yellow Fuel Pump 20 Amp Yellow TCM, A/C Clutch 25 Amp Natural Power Inverter 20 Amp Yellow Rear Heated Seats 20 Amp Yellow...
-
Page 68: Interior Fuses
MAINTAINING YOUR VEHICLE Interior Fuses • The fuse panel is on the lower instrument panel just to the left of the steering column. Cavity Mini-Fuse 30 Amp Green 15 Amp Blue 10 Amp Red 20 Amp Yellow 10 Amp Red Spare 20 Amp Yellow Spare... -
Page 69: Tire Pressures
MAINTAINING YOUR VEHICLE Cavity Mini-Fuse 15 Amp Blue Spare (R/S) 10 Amp Red Spare (Acc Delay) 15 Amp Blue 10 Amp Red 10 Amp Red TIRE PRESSURES • Check the inflation pressure of each tire, including the spare tire, at least monthly and inflate to the recommended pressure for your vehicle. -
Page 70: Wheel And Wheel Trim Care
MAINTAINING YOUR VEHICLE WHEEL AND WHEEL TRIM CARE • All wheels and wheel trim, especially aluminum and chrome plated wheels should be cleaned regularly with a mild soap and water to prevent corrosion. • To remove heavy soil and/or excessive brake dust, use MOPAR equivalent or select a nonabrasive, non-acidic cleaner. -
Page 71: Consumer Assistance
CONSUMER ASSISTANCE CHRYSLER GROUP LLC CUSTOMER CENTER P.O. Box 21–8004 Auburn Hills, MI 48321–8004 Phone: 1–800–992–1997 CHRYSLER CANADA INC. CUSTOMER CENTER P.O. Box 1621 Windsor, Ontario N9A 4H6 Phone: 1–800–465–2001 ASSISTANCE FOR THE HEARING IMPAIRED • To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommunication Devices for the... -
Page 72: Reporting Safety Defects In The 50 United States And Washington, D.c
CONSUMER ASSISTANCE REPORTING SAFETY DEFECTS IN THE 50 UNITED STATES AND WASHINGTON, D.C. • If you believe that your vehicle has a defect that could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying the manufacturer. - Page 73 CONSUMER ASSISTANCE Disclaimer: • THE TIRE MANUFACTURER’S LIMITED WARRANTY PROGRAM, THE DETAILS OF WHICH CAN BE FOUND, ON THE OWNERS MANUAL DVD, THE TIRE MANUFACTURER’S WEBSITE OR AT ANY AUTHORIZED SERVICE CENTER ARE IN LIEU OF ALL OTHER REMEDIES OR WARRANTIES, EXPRESS OR IMPLIED, ARISING BY LAW OR OTHERWISE, INCLUDING FITNESS FOR A PARTICULAR PURPOSE OR...
- Page 74 CONSUMER ASSISTANCE Using Lift Kits • Use of lift kits with some vehicle/tire combinations can cause instability or loss of control. When changing tire sizes, always consult an installer for optimum rim width and carefully check vehicle/tire clearances. Check Your Tires For Damage •...
-
Page 75: Mopar Accessories
• The following highlights just some of the authentic Jeep Accessories by MOPAR have been engineered to customize your Jeep Commander. • To see the full line of accessories stop by your Jeep dealer or visit MOPAR.com CHROME: • Grille •... - Page 76 NOTES...
- Page 78 10XK74-926-AA Commander First Printing User Guide JEEP.com...
