1.1 INTRODUCTION

A Solar Controller (or Charge Controller / Regulator) is an essential component of your photovoltaic solar system. The Controller
maintains the life of the battery by protecting it from overcharging. When your battery has reached a 100% state of charge, the
Controller prevents overcharging by limiting the current flowing into the batteries from your solar array.
The GP-PWM-10-SQ is rated for a continuous solar current input of 10 amps, uses Pulse Width Modulation (PWM) technology
and a unique four stage charging system that includes an optional equalize setting to charge and protect your battery bank.

1.2 SPECIFICATIONS

DESCRIPTION
Rated solar panel amps for 10A/10AW
Nominal System Voltage
Max. solar cell array voltage (output has no load)
Lowest operating voltage (solar or battery side)
Max voltage drop-solar panel to battery
Min battery start charging voltage
Soft start charging voltage
Soft start charging current (50% PWM duty)
Bulk charge voltage
Absorption charging voltage at 25°C
LTO type battery
GEL
AGM (Default)
LiFePO4
WET
Calcium
Absorption transits to Equalizing or Float condition:
Charging current drops to
Or Absorption charging timer timed out
Equalizing charging active
Only for WET or Calcium battery
Automatic equalizing charging periodical
Equalizing charging voltage at 25°C
Equalizing charging timer timed out
Float charging voltage at 25°C
For LTO and LiFePO4 battery
For Gel, AGM, WET and Calcium
Voltage control accuracy
Battery temperature compensation coefficient
[page 4] | gpelectric.com

1. INSTALLATION OVERVIEW

VALUE
10A
15-22 VDC
25 VDC
8 VDC min
0.25 VDC
3 VDC
3-10 VDC (+/-0.2)
Up to 15 Amps
10-14.6 VDC (+/-0.2)
14.0 VDC (+/-0.2)
14.1 VDC (+/-0.2)
14.4 VDC (+/-0.2)
14.4 VDC (+/-0.2)
14.7 VDC (+/-0.2)
14.9 VDC (+/-0.2)
14.9 Amps (+/-0.1)
4 hours
10 VDC (+/-0.2)
28 days
15.5 VDC (+/-0.2)
2 hours
13.6 VDC (+/-0.2)
13.6/14.0 VDC (+/-0.2)
13.6 VDC (+/-0.2)
+/-1%
-24 mV/°C
Dimensions (H x W x D):
102 x 130 x 27 mm
4.02 x 5.12 x 1.06 in
Weight: 151 grams / 5.34 oz
Maximum Wire Gauge: #6 AWG
Warranty: 1 year
• PWM charging
• 4 Battery charging profiles
• 4 Stage charging
• Monthly equalize option
• Displays charging current, Bat-
tery voltage and battery state
of charge
• Reverse polarity protected
• Temperature compensated
• RoHS compliant
• Accepts up to 10 Amps DC
Input Current
The total rated Maximum Power Current
(Imp) of the PV input should not exceed
10 Amps
