This Quick Start is written with reference to the default configuration, VISIONPRO 308, unless
otherwise specified.
Ports and Connectors
Port
Description
Power Port
To connect the external power adapter of 12V DC (input).
Earth
To connect the telecom earth to the system.
CO
To connect the CO trunk lines from PSTN.
SLT
To connect station SLT phones, FAX machines.
RESET
To reset the SE/SA Password to its default value.
LED
LED
Description
PWR
To indicate system power ON/OFF condition.
STS
To indicate the system status during various conditions.
2
Matrix VISIONPRO Quick Start
