Design-2 and -3 – Signalling
The Bluetooth key sends signals as soon as it is inserted in the cylinder.
Comment
Normal mode
Battery is almost empty.
Replacing the battery
Locking authorisation OK
No locking authorisation
No locking authorisa-
tion, because the key is
currently outside of the
time zone
Bluetooth interface is
activated
Cylinder authorisation
update (only relevant for
CLIQ GO systems)
®
EN
28
Signalling (red / green)
Acoustic
–
3 x long
1 x short
3 x short
3 x short
1 x short
1 x short,
1 x long
Design-2 and -3 – Signalling
Visual
–
3 x long green
1 x short green
3 x short red
3 x short
red – green – red
1 x short green
1 x short green,
1 x long green
