Creative Playthings FUNTIME swing sets Assembly Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
MODEL MQHAR
AssEMbLy MAnuAL
(Slide Not Included)
If you have problems or questions about your Creative Playthings play set,
Contact Creative Playthings Customer service at 1-800-598-4997 or
All hardware on this set is specially coated
for corrosion resistance.
If non-Creative Playthings hardware is used,
it must be galvanized or stainless steel.
This product is intended for single
family home/residential use only and
not intended for use in any public
setting. Placement in any public
setting constitutes a misuse of this
product.
DO nOT CALL THE RETAILER.
customerservice@creativeplaythings.com
by
Creative Playthings®
Please read the owner's manual before the
assembly of your Play set. it provides additional
information on the care and use of your Play set.
you must carefully read the entire instruction man-
ual before proceeding with the assembly or use
of your new Play set.
Creative Playthings takes great care to design its
products with your child's safety in mind. How-
ever, only with careful supervision and proper
safety instructions, can you be assured of safe
play time on any product designed for children.
save these instructions for reference in case you
need to contact customer service.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FUNTIME swing sets and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Creative Playthings FUNTIME swing sets

Summary of Contents for Creative Playthings FUNTIME swing sets

  • Page 1 MODEL MQHAR Creative Playthings® AssEMbLy MAnuAL (Slide Not Included) If you have problems or questions about your Creative Playthings play set, DO nOT CALL THE RETAILER. Contact Creative Playthings Customer service at 1-800-598-4997 or customerservice@creativeplaythings.com Please read the owner’s manual before the All hardware on this set is specially coated assembly of your Play set.
  • Page 2 • until assembly is complete, DO nOT let your children use the Play set. • never fasten anything not approved by Creative Playthings to your Play set. Accessories or items not ap- proved by Creative Playthings include; Dog runs, clothes lines, electrical devices, or bird feeders etc.

  • Page 3: Safe Play Area

    (2 M) (2 M) Whichever is greater (4.27 M) Landscape Timbers 6' from (2 M) play structure. A fALL OnTO A HARD suRfACE COuLD REsuLT In sERIOus InjuRy. MODEL MQHAR Page 3 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)

  • Page 4: Hardware Bag Contents

    12017-206 Lock Washer 5/16" 17003-1611 Hex Bolt 5/16 x 4" More hardware is included than is required for assembly. MODEL MQHAR Page 4 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14) Other hardware with telescope steering wheel and Nameplate...
  • Page 5 #10 x 1-1/2" self-Drill screw 5/16 x 4-1/2" Hex bolt #6 x 1/2" Pan Head screw #12 x 3/4" Pan Head screw 5/16 x 5-1/2" Hex bolt MODEL MQHAR Page 5 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)

  • Page 6: Pre Assembly Information

    PRE AssEMbLy InfORMATIOn CREATIVE PLAyTHInGs Play sets usE A fEW sTAnDARD COnnECTIOns. bECOMInG fAMILIAR WITH THEsE COnnECTIOns WILL sIMPLIfy AssEMbLy AnD InsuRE A sAfER PLAy PRODuCT fOR yOuR CHILDREn. Hex bolt & Weld nut Assembly Procedure: Assembly Layout: Align the holes in the parts to be fastened. Start preliminary tightening of bolt into weld nut by hand.

  • Page 7: Maintenance Instructions

    • Check structure twice monthly during usage for any evidence of deterioration. If upon inspection, hardware has sharp edges, rusted or structural pieces have signs of premature failure; replace them through Creative Playthings Customer Service. • Oil all metallic moving parts monthly during the usage season.
  • Page 8 PLAysET VIEW (Slide Not Included) MODEL MQHAR Page 8 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)

  • Page 9: Component View

    Thus 33687-102 is marked 687. Take inventory of all parts, making sure nothing is missing or defective. If you find that parts are missing or defective call the Creative Playthings Customer Service Department at 1-800-833-4001. * Not marked on Play Set view page.
  • Page 10 1 50475-100 Playtime Play Pack 1 BW 1 33931-402 Platform Back 1x6x41-1/2" 1 50530-400 Glider Bracket Box 1 50530-700 Glider Bracket Hardware 1 50536-100 Funtime Nameplate Pack MODEL MQHAR Page 10 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 11 Try to align all of the holes along each board all of the holes along each board for attachments. for future attachments. future attachments. MODEL MQHAR Page 11 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 12 1/4" Flat Washers in the bottom holes. Fasten the Platform Back (BW) to the middle post assemblies in the same way. 2" Lag Screw in Bottom Holes MODEL MQHAR Page 12 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 13 9 – stringer: Fasten the Stringer (BE) to the Platform Front and Platform Back using two 1/4 x 3" Lag Screws and Flat Washers as 3" Lag shown. Screw MODEL MQHAR Page 13 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 14 Fasten the Left Wall Support to the back left post and Gym Roof Support (BS) using one 1/4" x 3-1/2" Hex Bolt Assem- bly through the top hole only. MODEL MQHAR Page 14 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 15 Lag Screw and Flat Washer through the top hole in each 1/4 x 3" Lookout Platform Side to finish securing the part to the gym. Hex Bolt, 1/4 x 2" Lag Screw bottom MODEL MQHAR Page 15 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 16 End using one 1/4 x 3" Lag Screw and Flat Washer. The top face of the upper Stringer will be well below the top of the Platform End. 1/4 x 3" Lag Screw MODEL MQHAR Page 16 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 17 Fasten the Center Ladder Do this first! Rail to the Inner Wall Bottom using on 1/4 x 3" Hex Bolt As- sembly. No fastener in this hole MODEL MQHAR Page 17 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 18 Center Ladder Rail lands. Fasten the Center Ladder Rail to the End Support using a 1/4 x 3" Hex Bolt Assembly with a Short Weld Nut. MODEL MQHAR Page 18 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 19 Rafters on the assembled panel. Align the ends. Fasten Roof Boards to the Roof Rafters using 1/8" diam- eter pilot holes and #8 x 1-5/8" Screws as with the first Roof Panel. MODEL MQHAR Page 19 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 20 IMPORTAnT: never leave a gap larger than 3-1/2" unless it is larger than 9". A gap of this size can introduce a situa- tion where a child's body can pass through but the child's head cannot. MODEL MQHAR Page 20 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 21 Fasten the Entrance Slats (AB) to the Right Wall Support and Rock Wall Mount using #6 x 1-1/8" Screws. Leave a gap of 19" between the Entrance Slats. MODEL MQHAR Page 21 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 22 Window Slats and Window uprights halfway be- tween the Panel Band and Left Wall Support. Fasten each Window Horizontal using four #6 x 1-1/8" Screws MODEL MQHAR Page 22 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 23 1/4" Flat Washers through the Grommets. If uneven, go back to the other Tent End and fasten the tent in a better #12 x 3/4" Pan Head Screw position before securing the final end. MODEL MQHAR Page 23 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 24 Evenly space Rock Boards and Spacer Boards (AA) in the opening between the existing Rock Boards. Alternate the orientation of the Rock Boards as shown. The gap between boards will be approximately 1/4". 1/4" Gap MODEL MQHAR Page 24 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 25 1/4 x 1-1/2" Hex Bolt Assemblies w/ Long Weld Nuts. Insert the Weld Nuts from the top of the Lunch Seat. 1/4 x 1" Hex Bolts w/Short Weld Nuts MODEL MQHAR Page 25 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 26 Fasten each Bracket-Rail assembly to the Top Rope Support using one 1/4 x 1" Hex Bolt Assembly. 1/4 x 1" Hex Bolt 1/4 x 1-1/2" Hex Bolt MODEL MQHAR Page 26 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 27 48a – Access Ladder brackets: Fasten one Access Bracket to inside of each Ladder Rail 1/4 x 1-1/2" using 1/4 x 1-1/2" Hex Bolt Assemblies as shown at right. Hex Bolt MODEL MQHAR Page 27 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 28 Screws with Flat Washers. From behind, secure the Chalkboard to the top and bottom 1/4 x 2" Chalk Battens using #12 x 3/4" Pan Head Screws. Lag Screw MODEL MQHAR Page 28 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 29 Fasten one Hand Grip (CX) to each Entrance Slat above the Cargo Net using two 1/4 x 1" Hex Bolt Assemblies with Short Weld Nuts for each. 1/4 x 1" Hex Bolt w/Short Weld Nuts MODEL MQHAR Page 29 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 30 Drill 3/16" diameter pilot holes 1" deep and secure each using two 1/4 x 1-1/2" Lag Screws and Flat Washers. 3/16" Pilot Drill & 1/4" x 1-1/2" Lag Screws MODEL MQHAR Page 30 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 31 Fasten another Swing Hanger at the other end of the Glider Bracket in the same way. Repeat with the other Glider 3/8" Flat Washer Bracket Swing Hanger for Glider MODEL MQHAR Page 31 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 32 5/16" x 3" Hex Bolt Assemblies to join the Front up- right, Back upright, Swing Beam and Triangle Plate (Cv) as shown at bottom left. 5/16 x 3" Hex Bolt MODEL MQHAR Page 32 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 33 Hex Bolt L-Brace to the Beam using one 5/16 x 3" Hex Bolt Assembly. Tighten all fasteners. 5/16 x 4-1/2" Hex Bolt 5/16 x 4-1/2" Hex Bolt MODEL MQHAR Page 33 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 34 Note: Do NOT use concrete to set Ground Stakes. Pound a metal spike or rod into the ground to start a hole in hard or rocky ground. MODEL MQHAR Page 34 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 35 Inspect your work; make sure all fasteners are secured properly and the area is clear of tools and other hazards before allowing children on the Swing Set. MODEL MQHAR Page 35 © Copyright 2013, Creative Playthings 19856-100 Rev D (05-14)
  • Page 36 Creative Playthings for warranty service and/or part replacement. The warranty can be found in your Owner’s Manual. Please fill out the warranty card on the back of your owners manual. your com- pleted warranty card will allow us to quickly process warranty claims.
