MODEL PS18SPH
ASSEMBLY MANUAL
If you have problems or questions about your Creative Playthings play set,
Contact Creative Playthings Customer Service at 1-800-598-4997 or
All hardware on this set is specially coated
for corrosion resistance.
If non-Creative Playthings hardware is used,
it must be galvanized or stainless steel.
This product is intended for single
family home/residential use only and
not intended for use in any public
setting. Placement in any public
setting constitutes a misuse of this
product.
DO NOT CALL THE RETAILER.
customerservice@creativeplaythings.com
™
Please read the owner's manual before the
assembly of your Play Set. it provides additional
information on the care and use of your Play Set.
You must carefully read the entire instruction man-
ual before proceeding with the assembly or use
of your new Play Set.
Creative Playthings takes great care to design its
products with your child's safety in mind. How-
ever, only with careful supervision and proper
safety instructions, can you be assured of safe
play time on any product designed for children.
Save these instructions for reference in case you
need to contact customer service.
By

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Playtime PS18SPH and is the answer not in the manual?

Questions and answers

Related Manuals for Creative Playthings Playtime PS18SPH

Summary of Contents for Creative Playthings Playtime PS18SPH

  • Page 1 ™ MODEL PS18SPH ASSEMBLY MANUAL If you have problems or questions about your Creative Playthings play set, DO NOT CALL THE RETAILER. Contact Creative Playthings Customer Service at 1-800-598-4997 or customerservice@creativeplaythings.com Please read the owner’s manual before the All hardware on this set is specially coated assembly of your Play Set.

  • Page 2: Assembly Safety

    • Until assembly is complete, DO NOT let your children use the Play Set. • Never fasten anything not approved by Creative Playthings to your Play Set. Accessories or items not ap- proved by Creative Playthings include; Dog runs, clothes lines, electrical devices, or bird feeders etc.

  • Page 3: Safe Play Area

    (2 M) (2 M) Whichever is greater (4.27 M) Landscape Timbers 6' from (2 M) play structure. A FALL ONTO A HARD SURFACE COULD RESULT IN SERIOUS INJURY. MODEL PS18SPH Page 3 © Copyright 2013, Creative Playthings 19861-300 Rev A (07-20)

  • Page 4: Hardware Bag Contents

    17003-1809 Hex Bolt 1/4 x 4-1/2" 17020-113 Screw #10 x 2-1/2" 17119-409 Truss Head Bolt 1/4 x 1" More hardware is included than is required for assembly. MODEL PS18SPH Page 4 © Copyright 2013, Creative Playthings 19861-300 Rev A (07-20)

  • Page 5: Pre Assembly Information

    PRE ASSEMBLY INFORMATION CREATIVE PLAYTHINGS PLAY SETS USE A FEW STANDARD CONNECTIONS. BECOMING FAMILIAR WITH THESE CONNECTIONS WILL SIMPLIFY ASSEMBLY AND ENSURE A SAFER PLAY PRODUCT FOR YOUR CHILDREN. Hex Bolt & Weld Nut Assembly Procedure: Assembly Layout: Align the holes in the parts to be fastened. Start preliminary tightening of bolt into weld nut by hand.
  • Page 6 AA934-204 2 Swings, 1 Trapeze* 8570-202 10 Ft. Wave Slide *Alternative swing features may be included with your set. Use the instructions packed with the swing equipment for assembly. MODEL PS18SPH Page 6 © Copyright 2013, Creative Playthings 19861-300 Rev A (07-20)

  • Page 7: Component View

    W 1 33756-102 Ladder Rail Right 2 x 3 x 63-1/2" 1 33922-102 Rock Wall Mount 5/4 x 6 x 39-1/2" * Not marked on Play Set View page. MODEL PS18SPH Page 7 © Copyright 2013, Creative Playthings 19861-300 Rev A (07-20)

  • Page 8: Maintenance Instructions

    • Check structure twice monthly during usage for any evidence of deterioration. If upon inspection, hardware has sharp edges, rusted or structural pieces have signs of premature failure; replace them through Creative Playthings Customer Service. • Oil all metallic moving parts monthly during the usage season.
  • Page 9 Arch (J). Align the hole at the center of the Platform Front closer to the upper end of the tower. 1/4 x 4" Hex Bolts in top holes, 1/4 x 2" Lag Screws in bottom holes. MODEL PS18SPH Page 9 © Copyright 2013, Creative Playthings 19861-300 Rev A (07-20)
  • Page 10 Left Post in the orientation shown using 1/4 x 3" Hex Bolt As- semblies. Note the hole positions along the board. t o w t o w MODEL PS18SPH Page 10 © Copyright 2013, Creative Playthings 19861-300 Rev A (07-20)
  • Page 11 Assembly Use a level to assure the right Midpost is plumb. Se- 3-1/2" Hex Bolt Assembly cure using one 1/4 x 2" Lag Screw and Flat Washer. MODEL PS18SPH Page 11 © Copyright 2013, Creative Playthings 19861-300 Rev A (07-20)
  • Page 12 All lag posts using 1/4 x 3" Lag Screws with Flat Washers. Be sure screws 3" to drill 3/16" diameter pilot holes before using the Lag Screws. MODEL PS18SPH Page 12 © Copyright 2013, Creative Playthings 19861-300 Rev A (07-20)
  • Page 13 The distance between the Rafters should be 30". Measure from corner to corner both ways. When the two diagonal measurements are the same, the rafters are square. 30" MODEL PS18SPH Page 13 © Copyright 2013, Creative Playthings 19861-300 Rev A (07-20)
  • Page 14 Support. The Roof Upright can now be moved to allow better access. Be sure to re-secure the connection after the Roof 1/4 x 4-1/2" Panels are in place. Hex Bolt MODEL PS18SPH Page 14 © Copyright 2013, Creative Playthings 19861-300 Rev A (07-20)
  • Page 15 Lower Wall Support using two 1/4 x 3-1/2" Hex Bolts each. Be sure to orient the Swing Mounts so the holes on the sides are closer to the top. 3-1/2" Hex Bolts MODEL PS18SPH Page 15 © Copyright 2013, Creative Playthings 19861-300 Rev A (07-20)
  • Page 16 Flat Washer for each end. Repeat with a second Picnic Support on the left Posts. 2 3 " 3-1/2" Lag Screws 4 " 1 0 - 1 / MODEL PS18SPH Page 16 © Copyright 2013, Creative Playthings 19861-300 Rev A (07-20)
  • Page 17 1-5/8" Screws as shown. Do not drive screws too deeply. Do not allow the tips of the screws to protrude from the top of the Table Boards. Parts omitted for clarity MODEL PS18SPH Page 17 © Copyright 2013, Creative Playthings 19861-300 Rev A (07-20)
  • Page 18 Platform Front. Secure the Brackets using 1/4 x 1" Hex Bolt Assemblies. Drill 5/16" dia. holes 1-3/8" 1/4 x 1" Hex Bolts 1/4 x 1" Hex Bolts MODEL PS18SPH Page 18 © Copyright 2013, Creative Playthings 19861-300 Rev A (07-20)
  • Page 19 1/4 x 1-1/2" Hex Bolts, 1/4 Lock Washers, 8mm Flat holes for the screws to prevent splitting. Washers and 1/4" Weld Nuts. Gaps approx. 7/8" 1/4" Lock Washer 8mm Flat Washer 1/4 x 1-1/2" Hex Bolt MODEL PS18SPH Page 19 © Copyright 2013, Creative Playthings 19861-300 Rev A (07-20)
  • Page 20 This presents extreme danger to long you can tie your children. extra knots along the length of the rope. If too short, remove knots. 11" Typical Overhand Knot MODEL PS18SPH Page 20 © Copyright 2013, Creative Playthings 19861-300 Rev A (07-20)
  • Page 21 Weld Nut in the Framing Member. Re-attach the Platform Board and continue securing the Slide. MODEL PS18SPH Page 21 © Copyright 2013, Creative Playthings 19861-300 Rev A (07-20)
  • Page 22 Swing Set. Save all instruction sheets and receipts in case it becomes necessary to contact Creative Playthings for warranty service and/or part replacement. The warranty can be found in your Owner’s Manual.
