5 Product information

5.1 Data plate

Property
Speed
Discharge nominal diameters DN
Flange standard
Limit of fluid temperature (min./max.)
- Mechanical seal version [°C]
-Gland packing version [°C]
Limits of ambient temperature (min./max.) [°C]
Ambient humidity
Motor insulation class
Motor protection level
Electrical protection for motor
Acoustic pressure level, (In accordance with
motor performances)
Standard fluid allowed
Electrical connections
Installation and operating instructions WILO-Split Case Pumps

5.2 Type key

SCP 200 – 320 HA
SCP Name of the range
200 Discharge flange nominal diameter
in mm
320 Nominal diameter of the impeller in mm
HA Type of Hydraulic:
- HA = Standard type version A
- HB = Standard type version B
- HS = Single suction impeller
- DV = Double volute
- DS = Double stage

5.3 General description

Limits of usage of the standard range
The technical features of the product have been
described in the offer made for this product,
especially the fluid compatibility. Please refer to
this:
Value
2900, 1450, 980 1/min
50 up to 400
PN 16/25
Ambient Temperature
-5 up to +60
< 90 %
F
IP 55
–
–
Central heating liquid in accordance
with VDI 2035, cooling water.
Cold water
Mixture water/glycol up to 40 % of
volume. Temp ≤ 40 °C for concentrations
between 20% and 40% vol.
Contact WILO for all other fluids
3~230V, 50Hz (≤4kW)
3~415V, 50Hz (≥5,5kW)
Remarks
Model dependent
Model dependent
ISO 7005-2, as needed
other on request
other on request
required in place (in accordance
with local regulation)
Refer to the data plate on the
motor on in technical leaflets
Standard version
Standard version
Only for special version
Other frequency, voltages,
please contact WILO
11
