In automatic mode, the meanings of the indications are:
Display Meaning
indication
0. Idle position, waiting for a change in the control value or feedback.
1.
Actuator sends closed.
2. Actuator sends open.
3. Waiting position after turning on (when controlled via 0-10V or 10-0V).
4. Waiting position after turning on (when controlled via and I own network; duration is dependent
on the address).
5. Minimum waiting position after a sending action.
6. Idle position in which the control is determined by the remote control.
7. Actuator is standing still against a limiting switch.
A. Stopped closing.
B. Stopped opening.
C.
Additional delay of 2 seconds after a sending action.
U. Due to problems, the IMS now controls based on the predefined position.
L. Due to the I/O network going down, the IMS now runs independently based on its own
temperature measurements.
Adjust the close and open limit switches of the connected actuator. If necessary, it is possible to connect the limit
switches to the IMS. Remove the jumper on terminals Cl, Op and C (limit switches) before connecting.
Most 1 fase actuators have the limit switches between their power lines. Leave the jumper on terminals
Cl, Op and C (limit switches).
