- Page 1 Z808B Model： Wireless Dimmable Power Plug with Power Monitoring LCD & USB Port Wireless Dimmable Power Plug with Power Monitoring LCD & USB Port User Manual Firmware: V5.1 Hardware: V2.4...
-
Page 2: Table Of Contents
Table of Content 1. INTRODUCTION......................... 4 2. PRODUCT CHARACTERISTICS....................4 3. OPERATION INSTRUCTIONS....................4 3.1 P ..........................4 OWER ON 3.2 J ........................5 OIN THE NETWORK 3.3 E ........................5 EVICE 3.4 U ........................6 NDER CONTROL 3.5 A ..................... 6 LLOW NETWORK JOIN FUNCTION 3.7 R... - Page 3 Load Socket Binding Key LCD Display Function Key USB Port 1 USB Port 2 Z808B Appearance...
-
Page 4: Introduction
The Z808B device can detect the current, voltage, power and energy of the load. At the same time, the Z808B can be bound to the control device with the switch function/level control function, and the Z808B switch/level can be controlled by the bonded device . -
Page 5: Join The Network
10.5 kWh. 3.3 End Device Bind Z808B can bind device such as the client end having ON / OFF cluster with control or level control cluster such as Netvox Z503/Z501, binding operation is as follows : a) Press the binding key for 3 seconds till . -
Page 6: Under Control
3.5 Allow network-join function As a router in the network, the Z808B has the function of allowing other devices to join the network as its sub devices. At the same time, press the binding button and the function button for 1 second. -
Page 7: Restore Factory Settings
(in amps), power (in watts), and power (in kWh). 3.7 Restore factory settings After the Z808B joins the network , it will save its assigned network address. If users want to join a new network, users need to restore the device to the factory settings first. - Page 8 3.9 ZigBee Description 1.End Point(s) : 0x01 2.Device ID : Dimmer Light (0x0101 ) 3.Cluster ID which the endpoint supports Cluster ID for Z808B Server side Client side EP 0X01 (Device ID: Dimmer Light (0x 0101 ) Basic ( 0x0000 )
-
Page 9: Product Attributes And Custom Instructions
Enabled 3.10 Product attributes and custom instructions 1. The cluster that Z808B uses is refer to SE in Simple Metering used in the Cluster ID ( 0x0702 ) and Electrical the Measurement the ClusterID (0x0B04) , and the Cluster ID ( 0x0702 ) in NETVOX custom current, voltage, power, energy attribute . -
Page 10: Load Characteristics
ATTRID = 0xE002 ( or 0x0400), the unit is W ; 2 ) Current ATTRID=0xE000, the unit is mA; voltage ATTRID = 0xE001, the unit is V 2 . Custom command The instruction format for erasing the current battery information is: CMD=0CE0 ADDRMODE DSTADDR... -
Page 11: Installation Methods And Precautions For Use
6. Installation Methods and Precautions for This product does not have a waterproof function. After the screening is completed, please place it indoors. Note: 1. The device has over-current and over-voltage protection function. If the current exceeds 3A , the device will turn off the load lamp within 2 seconds. Backlight flashes 10 times (10, 250, 250). -
Page 12: Maintenance
7. Maintenance Your device is a product of superior design and craftsmanship and should be used with care. The following suggestions will help you use the warranty service effectively. • Keep the equipment dry. Rain, moisture, and various liquids or moisture may contain minerals that can corrode electronic circuits.
