  • Page 1: User Manual

    ZigBee - Motion On-Off Switch User Manual Motion On-Off Switch Model: ZB11B 20140109 FW V2.0 HW V1.0...

  • Page 2: Table Of Contents

    Table of Contents 1. Introduction................................2 2. Product Appearance..............................3 3. Specification................................4 4. Installation.................................4 5. Setting up ZB11B..............................5 5-1. Turn On/ Turn Off ZB11B..........................5 5-2. Join the ZigBee Network..........................6 5-3. Binding................................6 5-4. Sleeping Mode..............................6 5-5. Wake up ZB11B..............................7 5-6.

  • Page 3: Introduction

    1. Introduction Netvox ZB11B, an infrared radiation (IR) motion sensor, acts as an End Device in ZigBee network. It does not perform permit-join function as a coordinator or a router for other devices to join the network. When ZB11B detects movement, it reports the message based on how bright the location is. Users can assign specific ON/OFF task to the binding devices according to different report.

  • Page 4: Product Appearance

    2. Product Appearance Indicator (Red/ Green) Binding Key Auxiliary Key Infrared Sensor Light Sensitivity Adjustor Sensor Sensitivity Adjuster Release Button...

  • Page 5: Specification

    3. Specification  Fully IEEE 802.15.4 compliant (ZigBee Pro) Utilizes 2.4GHz ISM band; up to 16 channels   Power supply: 2 x ER14505 3.6V AA batteries  Operating consumption: ≤ 45mA  Standby consumption: ≤ 100uA  Sensing angle- horizontal: 110°; vertical: 60° ...

  • Page 6: Setting Up Zb11B

    5. Setting up ZB11B 5-1. Turn On/ Turn Off ZB11B Under the circumstances ZB11B is first time used or after resetting, when it is powered on and cannot successfully search a network, ZB11B will go into turn-off mode. To manually turn on or turn off ZB11B, please use the following instructions:...

  • Page 7: Join The Zigbee Network

    A. Turn it on: Press the Binding Key once. The indicators will flash once, and the device is ready to be used. B. Turn it off: Press and hold the Binding Key for 15 seconds. The indicator will keep flashing. Release the Binding Key, and the device would be turned off.

  • Page 8: Wake Up Zb11B

    5-5. Wake up ZB11B When users would like to setup or acquire data from the device which is in sleeping mode, we have to wake up the device as the following steps: Step1. Press the Auxiliary Key. Step2. The indicator flashes green 5 times when ZB11B is online.

  • Page 9: Restore To Factory Setting

    5-8. Restore to Factory Setting To restore it to factory setting, please follow the steps: Step1. Press and hold the Auxiliary Key for 10 seconds. Step2. Release the button after the indicator shows fast green flashes to complete the restore.

  • Page 10: Home Automation Clusters For Zb11B

    Unsigned 0x00 – Read only 8-bit integer 0xff 0x0003 HWVersion Unsigned 0x00 – Read only 8-bit integer 0xff 0x0004 ManufacturerName Character 0 – 32 Read only netvox string bytes 0x0005 ModelIdentifier Character 0 – 32 Read only ZB11BE3E string bytes...
  • Page 11 Identifier Name Type Range Access Default Mandatory / Optional 0x0006 DateCode Character 0 – 16 Read only string bytes 0x0007 PowerSource 8-bit 0x00 – Read only 0x03 Enumeration 0xff 0x0010 LocationDescription Character 0 – 16 Read/write string bytes 0x0011 PhysicalEnvironmen 8-bit 0x00 –...

  • Page 12: Important Maintenance Instructions

    7. Important Maintenance Instructions  Please keep the device in a dry place. Precipitation, humidity, and all types of liquids or moisture can contain minerals that corrode electronic circuits. In cases of accidental liquid spills to a device, please leave the device dry properly before storing or using.
  • Page 13 FCC Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
