netvox R711 User Manual

Temperature and humidity sensor
Hide thumbs Also See for R711:

Advertisement

Quick Links

Download this manual
R711
Model：
Wireless Temperature and Humidity Sensor
Temperature and Humidity Sensor
R711
User Manual
Copyright©Netvox Technology Co., Ltd.
This document contains proprietary technical information which is the property of NETVOX Technology. It
shall be maintained in strict confidence and shall not be disclosed to other parties, in whole or in
part, without written permission of NETVOX Technology. The specifications are subject to change without
prior notice.

Advertisement

loading
Need help?

Need help?

Do you have a question about the R711 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for netvox R711

Summary of Contents for netvox R711

  • Page 1 User Manual Copyright©Netvox Technology Co., Ltd. This document contains proprietary technical information which is the property of NETVOX Technology. It shall be maintained in strict confidence and shall not be disclosed to other parties, in whole or in part, without written permission of NETVOX Technology. The specifications are subject to change without...

  • Page 2: Table Of Contents

    Table of Content 1. Introduction ........................... 2 2. Appearance ..........................3 3. Main Features ........................3 4. Set up Instruction ........................4 5. Data Report ..........................5 6. Control Command ......................... 6 7. Installation ..........................9 8. Important Maintenance Instruction ..................10...

  • Page 3: Introduction

    1. Introduction R711 is a long distance wireless temperature and humidity sensor based on LoRaWAN open protocol (Class A). LoRa Wireless Technology: LoRa is a wireless communication technology dedicated to long distance and low power consumption. Compared with other communication methods, LoRa spread spectrum modulation method greatly increases to expand the communication distance.

  • Page 4: Appearance

     The product has low power consumption and supports longer battery life. Note *: The battery life is determined by the frequency and other variables reported by the sensor. Please refer to http://www.netvox.com.tw/electric/electric_calc.html On the website, users can find various models of battery life in different configurations...

  • Page 5: Set Up Instruction

    4. Set up Instruction On/Off Insert batteries. (Open the battery back cover and insert two 1.5V AA size Power on batteries into the battery slot) Turn on Press and hold the function key till the green indicator flashes once. Turn off Press and hold the function key for 5 seconds till the green indicator flashes (Restore to factory setting) 20 times.

  • Page 6: Data Report

    1. The cycle of the device sending the data report is according to the default. 2. The interval between two reports must be MinTime. Please refer Netvox LoRaWAN Application Command document and Netvox Lora Command Resolver http://www.netvox.com.cn:8888/page/index to resolve uplink data.

  • Page 7: Control Command

    0x01 (2bytes (2bytes （2byte ReportReq (1byte (2byte Unit:s) Unit:s) Unit:0.1v) Unit:0.01℃) Unit:0.01%） Config Status Reserved 0x81 ReportRsp (0x00_success) (8Bytes,Fixed 0x00) R711 0x01 ReadConfig Reserved 0x02 ReportReq (9Bytes,Fixed 0x00) Battery Temperature Humidity MinTime MaxTime ReadConfig Change Change Change 0x82 (2bytes (2bytes （2byte...
  • Page 8 Example#1 based on MinTime = 1 Hour, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange=0.1V Note: MaxTime=MinTime. Data will only be report according to MaxTime (MinTime) duration regardless BtteryVoltageChange value. Example#2 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V. Example#3 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e.
  • Page 9 1) The device only wakes up and performs data sampling according to MinTime Interval. When it is sleeping, it does not collect data. 2) The data collected is compared with the last data reported. If the data change value is greater than the ReportableChange value, the device reports according to MinTime interval.

  • Page 10: Installation

    This product does not have a waterproof function. After the join into LoRa network, please place it indoors. 1. Please screw the bracket into the wall. Temperature and Humidity Sensor (R711) is suitable for the following scenarios:  Family  School ...

  • Page 11: Important Maintenance Instruction

    8. Important Maintenance Instruction Kindly pay attention to the following in order to achieve the best maintenance of the product: • Keep the equipment dry. Rain, moisture and various liquids or water may contain minerals that can corrode electronic circuits. In case the device is wet, please dry it completely. •...
