Page 1: User Manual
ZigBee -Power Socket with Power Consumption Monitoring User Manual Dimmable Socket with Power Detection Model: Z809B Energy Consumption Monitoring Series For Home Automation 20150105 FW V5.0 HW V1.3... - Page 2 Other Netvox related devices Switch controller Z809B Simple controller Z501 series Multiple/Scene controller Z503 Wall switch ZB02 series Light sensing switch Z302B On/Off Status Indicator (red | green) Network Indicator (red | green) Button switch Binding key...
-
Page 3: Product Specification
Introduction NETVOX Z809B is a ZigBee Home Automation enabled power socket with level control and power/energy/current/voltage consumption monitoring. It acts as a router device in the Home Automation profile network. It can be manually switched through a soft on/off switch or switched wirelessly through a paired remote controller. Consumption reading can be captured and displayed on ZiG-BUTLER -Netvox application software, or on any party ZigBee enabled in-home display. - Page 4 Startup and Network Association tep 1. To allow Z809B to function, it must first join to a ZigBee network. When it is given powered it will automatically start searching for an existed network. So before you give power to Z809B, please make sure it is within the wireless coverage distance (150 meters or less)
- Page 5 When binding is successful the green indicator on Z809B will flash 5 times then return to solid lit. If successful you should be able to wireless control Z809B. Otherwise it flashes quickly 10 times indicating pairing unsuccessful. Clear pairing setting: You may remove the pairing between the two or more devices.
- Page 6 Operation: If the Z809B device is properly paired with a switch device, you should see Z809B respond to on or off instruction wirelessly. When the Off button is press twice and then press On button once, Z809B will stay Off. This is to prevent from accidental turning the device on.
- Page 7 Permit other device to join Z809B is featured to be a router in the network. It permits other devices to join the network. In normal operation, by default the router device Z809B does not permit any device to join to the network to protect the network from unexpected or unauthorized join attempt. You will need to open up the permit-join on Z809B or on other router device to allow new devices (a router or an end device) to join.
-
Page 8: Restore To Factory Setting
Resetting Power Consumption Summation Z809B updates and stores the last energy reading in kwh. In some cases user would wish to return the counter to zero. Same feature can be found in ZiG-BUTLER software with the Recalculate button. Operation: Hold press Binding Key for 20 seconds then release the key when the... - Page 9 Summary of Key function and corresponding display Function Display Restore to factory Hold press binding key 3 flashes (hold press setting 15s then within 2s binding key) press test button once. Then 10 flashes if successful Permit Join Short press binding Flashes 60 times in key once 60 seconds.
-
Page 10: Configuration Setting
How to use Z809B section, when the Off button is press twice and then press On button once, Z809B will stay Off. This is to prevent from accidentally turning the device on. This is a factory default setting. Programmer may, however, overwrite this setting permanently by setting On Level attribute to any value between 0x00 to 0xFE. - Page 11 Clusters of Home Automation for Z809B 1.End Point(s)：0x01 2.Device ID：Dimmer Light (0x0101 ) 3.EndPoint Cluster ID Cluster ID for Z809B Server side Client side EP 0x01 (Device ID: Dimmer Light (0x0101 ) Basic（0x0000） None Identify (0x0003) Groups (0x0004) Scenes (0x0005)
- Page 12 Mandatory Identifier Name Type Range Access Default / Optional 0x0004 ManufacturerName Character – Read netvox string Bytes only 0x0005 ModelIdentifier Character 0 – 32bytes Read Z809BE string only 0x0006 DateCode Character 0 – 16 bytes Read 2014112 string only 0x0007...
-
Page 13: Important Maintenance Instructions
Important Maintenance Instructions As the device is not water proof it is recommended to keep the device in a dry place. Liquid and heavy moisture contains minerals that may oxidize the electronic circuitry. In case of liquid spill, please leave the device to completely dry before storing or using. ...
