1.
Evaluation Kit Specifications
Table 1-1.
Characteristic
PCB
PCB Material
Clock Speed
Ports
Memory
Board Supply Voltage
ROHS
CE and FCC Part 15 status
1.1
Electrostatic Warning
Warning:
Electrostatic
1.2
Battery
The ATSAM4C-EK ships with a 3V coin battery. This battery is not required for the board to start up as long as Jumper
JP8 is closed.
The coin battery is provided for user convenience in case the user would like to exercise the date and time backup
function of the SAM4C devices when the board is switched off.
1.3
Recovery Procedure
The demo software is stored in internal Flash memory. If the content of the internal Flash has been erased, it can be
reprogrammed recovered to the state as it was when shipped by Atmel using Atmel SAM-BA
available on the Atmel website (www.atmel.com/tools/atmelsam-bain-systemprogrammer.aspx). The binary file of the
demo software is available on the Atmel website in the ATSAM4C-EK Evaluation Kit Section
(http://www.atmel.com/tools/SAM4C-EK.aspx).
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Downloaded from
Downloaded from
Downloaded from
Downloaded from
Evaluation Kit Specifications
ESD-Sensitive Electronic Equipment!
The evaluation kit is shipped in a protective anti-static package. The board system must not
be subjected to high electrostatic discharge.
sensitive
We strongly recommend using a grounding strap or similar ESD protective device when
device
handling the board in hostile ESD environments (offices with synthetic carpet, for example).
Avoid touching the component pins or any other metallic element on the board.
Specifications
6 layers, 140 mm x 100 mm
Standard FR4 in 1.6 mm thickness
Crystal 8 MHz
Piezoelectric Ceramic Resonator 8.192 MHz
32.768 kHz external clock
RS232
RS485
USB
TWI EEPROM
Serial Data Flash
5V DC from main connector power supply
5V DC from USB
3V Battery for Backup and RTC
Compliant
Compliant
®
In-system Programmer
ATSAM4C-EK [USER GUIDE]
11251A–ATARM–16-Dec-13
