V
ALCOM
NETWORK
INTERFACE
FRONT
Figure 2. Speaker Mounting (Flexhorn supplied attached to grille)
RJ45 NETWORK
CONNECTION
BROWN
WHITE/BROWN
GREEN
WHITE/GREEN
ORANGE
WHITE/ORANGE
BLUE
WHITE/BLUE
STANDARD
RJ45 PATCH CABLE
SIDE
Figure 1. Signal Connections
4
RJ45
BROWN
BROWN
WHITE/BROWN
GREEN
WHITE/GREEN
ORANGE
WHITE/ORANGE
BLUE
WHITE/BLUE
BLUE
VM-186
(T568B)
VALCOM
PAGING HORN
CALL IN SWITCH
NORMAL OPEN
MOMENTARY CLOSED
(OPTIONAL)
947774
