H-6306, H-6307
H-7031
SIT/STAND DESKTOP
RISER
TOOL NEEDED
Phillips Screwdriver
Desktop x 1
Keyboard Tray x 1
1.
Set desktop on large surface to prevent falling/
tipping. Extend to full height by pushing up on the
paddle on the right side. (See Figure 1)
NOTE: It is recommended that two people
move the desktop.
CAUTION! Do not place hands near the
support bars, as they change position during
adjustment. Doing so may cause bodily harm.
Figure 1
PAGE 1 OF 6
1-800-295-5510
uline.com
PARTS
Left Connecting
Right Connecting
Plate x 1
ASSEMBLY
2. Place covers onto the connecting arms. (See Figure 2)
3. Flip keyboard tray upside down. Insert connecting
Pour le français, consulter les pages 5-6.
Cover x 2
Plate x 1
Figure 2
plates and fasten to keyboard tray using eight
screws. (See Figure 3)
Figure 3
Para Español, vea páginas 3-4.
Screw x 8
Cable Tie x 4
0521 IH-6306
