Table 8, Ethernet Pinouts (standard RJ45)
Pin No.
1 TX+
2 TX-
3 RX+
4 NC
5 NC
6 RX-
7 NC
8 NC
The Ethernet port is 10/100 autosensing and can be configured
as either DHCP or static IP. the configuration is done via the
set-up menu on the front panel. The pin-outs are standard RJ45
and can be found in Table 8 (above). The port supports all
Xicom protocol packetized in standard TCP/IP format. For more
information see protocol Chapter 5.
Table 9, W/G Switch 1 Pinouts
Pin No.
1 Position "A" command (+24 V active high)
2 Position "B" command (+24 V active high)
3 Command return (ground)
4 Position "A" indicator (active low)
5 Position "B" indicator (active low)
6 Indicator return (ground)
7 RF inhibit (normally closed to ground)
8 RF inhibit return (ground)
9 Summary fault 1 (input fault open)
10 Summary fault (output normally low)
11 Address select 1 (input low to select)
