NXP Semiconductors QorIQ T2080 Quick Start Manual

T2080RDBPCQS
QorIQ T2080 Reference Design Board (T2080RDB-PC) Quick Start
Rev. 1 - 08/2021

1 Introduction

The T2080 reference design board (T2080RDB-PC) system is a hardware
board, supporting the NXP QorIQ
four dual-threaded e6500 cores and speed up to 1.8 GHz.
For the T2080 RDB system, the prototype part number is X-T2080RDB-PC and
the production part number is T2080RDB-PC.

2 Related documentation

Some of the documents listed in the table below may be available only under
a non-disclosure agreement (NDA). To request access to these documents,
contact your local field applications engineer or sales representative.
Table 1. Useful references
Document name
QorIQ T2080 Reference Design
Board (T2080RDB-PC) User Guide
QorIQ T2080 Reference Manual
T2080 Product Brief
QorIQ T2080 Data Sheet

3 Preparing board

This board has two working modes, the Standalone mode and PCIe Endpoint mode. By default, the system is in the Standalone
working mode with 1U chassis. For the PCIe Endpoint mode operation, take the board out from the 1U chassis and install PCIe
bracket on the board. Now, the board can be plugged into a PCIe x4 slot in X86 server, and it can work as a PCIe card.
shows the I/O of the front panel of the 1U chassis, and
®
T2080 Power Architecture
Description
This document explains the
procedure to build, configure, and
use different components for the NXP
T2080RDB board.
This document provides a detailed
description on T2080 QorIQ
multicore processor, and on some of
its features, such as memory map,
serial interfaces, power supply, chip
features, and clock information.
This document provides an overview
of the NXP T2080 features, and
usage examples of T2080.
This document contains
T2080 information on
pin assignments, electrical
characteristics, hardware design,
considerations, package information,
and ordering information.
Figure 2
Contents
1
2
3
®
processor with
4
4.1
4.2
4.3
5
6
7
7.1
7.2
7.3
8
9
shows the PCIe card.
User Guide
Introduction.................................1
Related documentation...............1
Preparing board..........................1
System board interface...............3
Block diagram......................... 3
Features.................................. 4
Port map .................................5
Flash image layout..................... 5
Default RCW setting................... 6
Switch settings............................7
Switch default settings (NOR
flash boot)............................... 7
Other boot source settings...... 7
Switch detailed description......8
How to program flash for the first
time (without U-Boot)..................9
Revision history........................ 10
Figure 1
