  • Page 1 Quick Start Guide TRK-S12ZVHY64 S12 MagniV MCU for Motorcycle Instrument Cluster Applications...
  • Page 2 Quick Start Guide for TWRPI-MMA845xQ Quick Start Guide Get to Know the TRK-S12ZVHY64 Potentiometer Potentiometer Enable C Header User Buttons SPI Header Power Connector S12ZVHY64 Power Switch Stepper Motor Headers Program/Debug User LEDs Reset Button SCI Interface OSBDM Bootloader LIN Interface Speaker CAN Interface Mode Enable...
  • Page 3 TRK-S12ZVHY64 TRK-S12ZVHY64 Introduction and Default Settings The TRK-S12ZVHY64 features the This guide will show how to quickly S12ZVHY64 MCU, an automotive 16-bit connect the board to a host PC and MCU for automotive and motorcycle execute a demonstration application instrument cluster applications. The preloaded in to the flash memory.
  • Page 4 Quick Start Guide for TWRPI-MMA845xQ Quick Start Guide...
  • Page 5 TRK-S12ZVHY64 Software Tools Installation Install CodeWarrior Launch the Demo Development Studio Program Freescale’s CodeWarrior for MCUs The DVD contains a CodeWarrior project integrates the development tools to exercise the different modules of the for several architectures, including S12ZVHY MCU family, including the ADC, the S12Z architecture, into a single TIM, LCD, key interrupts, SCI and CAN product based on the Eclipse open...
  • Page 6: Setting Description

    Quick Start Guide for TWRPI-MMA845xQ Quick Start Guide Jumper Default Configuration Jumper Setting Description Potentiometer enabled Switch 1 enabled Switch 2 enabled Switch signals high when pressed (5 V) Switch signals pulled down Switch 3 enabled Switch 4 enabled Connect VDDX to its ballast transistor output Connect VDDX to VDDA Connect VSUP to VBATT Connect VDDX to VDDM...
  • Page 7: Jumper Description

    TRK-S12ZVHY64 Jumper List and Description Jumper Description Potentiometer enable Closing this jumper connects the potentiometer signal to an ADC channel Switch 1 enable Closing this jumper connects the SW to the MCU Switch 2 enable Closing this jumper connects the SW to the MCU Switch supply selector Pins 1-2 closed: Switches connect to GND when pressed Pins 2-3 closed: Switches connect to 5 V when pressed...
  • Page 8 Quick Start Guide for TWRPI-MMA845xQ Quick Start Guide Jumper List and Description, cont. Jumper Description SCI transceiver power Closing this jumper powers the SCI transceiver circuit SCI TX Selector Pins 1-2 closed: MCU SCI TX pin is connected to the virtual SCI module (via OSBDM) Pins 2-3 closed: MCU SCI TX pin is connected to SCI transceiver Speaker tone control enable Closing this jumper connects speaker amplifier to the MCU...
  • Page 9 TRK-S12ZVHY64 Headers and Connectors List Header/ Connector Description GPIO header (LCD replacement option), ports A, D and F GPIO header, port AD C header GPIO header (LCD replacement option), ports B, H, G and F Extended debug lines GPIO header, ports T and S SPI header Main power barrel connector (up to 18 V) Stepper motor 0 header...
  • Page 10: Port Description

    Quick Start Guide for TWRPI-MMA845xQ Quick Start Guide Peripheral List Peripheral Port Description Potentiometer Potentiometer connected to ADC channel 0 Blue LED connected to port P0 Blue LED connected to port P1 Blue LED connected to port P2 Blue LED connected to port P3 VBATT LED, ON when voltage is applied to the board MCU PWR LED, ON when the MCU is regulating the input voltage to 5 V...
  • Page 11 TRK-S12ZVHY64...
  • Page 12: Warranty

    Quick Start Guide Quick Start Guide Quick Start Guide Support Visit freescale.com/support for a list of phone numbers within your region. Warranty Visit freescale.com/warranty for complete warranty information. For more information, visit freescale.com/TRK-S12ZVHY64 Freescale, the Freescale logo and Qorivva are trademarks of Freescale semiconductor, Inc., Reg.
