CommScope FIST-RSKG-16 Installation Instructions

TC-910-IP Rev. C, March 2021
1

About this manual

This kit is used to install 16 drop cables up to 2,4 mm diameter in a new unused round port of the FIST-GCO2-BX6 and
BX8, the FIST-GC02-FX and the FIST-EDSA2.
2

Kit contents

N°
1 FIST GCO2 RSKG-16 with securing screws and blind plugs
2 O-ring
3 Cable term GC02 brkt 16 OUT
4 Cable term GC02-FX brkt 16 OUT
5 Bolt with star washer
6 Mini termination units
7 Lubrication oil
3

Cable diameter range gel seals

Number of ports
1
2
3
4
4 FLAT
860661094 Rev. A
