CommScope FOSC-450D Installation Instruction

CommScope FOSC-450D Installation Instruction

Fiber optic splice closure

Advertisement

Quick Links

TC-761-IP
Rev A, Feb 2017
www.commscope.com
Content
Fiber Optic Splice Closure
1 Introduction
2 General
2.1 Kit content
2.2 Tools
2.3 Accessories
2.4 Capacity
3 Preparation of the closure
4 Cable preparation
4.1 Looped cable
4.2 Drop cable
1
Introduction
The FOSC-450 is an environmentally sealed enclosure for the fiber management system that provides the function
of splicing in the external network.
The FOSC-450 has provision for all cable terminations and sealing requirements.
The closure is a single ended design made of a thermoplastic material. The base and dome are sealed with
a clamp and O-ring system. For cable sealing , a wrap-around block with 6 ports is used that contains a pre-
installed gel profile. One can terminate 6 cables, with a diameter of minimum 9 mm and maximum 25 mm.
It can be opened and closed repeatedly without replacing or changing components.
FOSC-450D
I N S T A L L A T I O N
5 Cable termination
6 Fiber routing
6.1 Fiber routing to the basket
6.2 Fiber routing to the tray
6.3 Fiber routing on the tray
7 Installation of the gel block
8 Grounding
9 Closing the closure
I N S T R U C T I O N

Advertisement

loading
Need help?

Need help?

Do you have a question about the FOSC-450D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CommScope FOSC-450D

  • Page 1 FOSC-450D I N S T A L L A T I O N I N S T R U C T I O N TC-761-IP Rev A, Feb 2017 Fiber Optic Splice Closure www.commscope.com Content 1 Introduction 5 Cable termination...
  • Page 2: Cable Preparation

    General 3 Preparation of the closure Kit content Open the clamp and remove the dome. Position and secure the closure tower properly to the work • Dome station. • Base O-ring system • Cable attachment plate with tower • Gel block with trigger •...
  • Page 3 Cable termination Looped cable Loose tube cable Loose tube cable 4.1.1 Make a window cut of 3.5 m. Cut the strength member at a distance of 70 mm. Central core cable Install the strength member termination plate. 30 mm 65 mm 100 mm Install the cable retention device on the cable, tighten the hose 4.1.2...
  • Page 4 Central core cable Fiber routing Fiber routing to the basket In case of two strength members, first bend the central plate backwards. 6.1.1 Install the looped cable in ports 5 and 6 for proper routing to the basket of the tray. Loose tube Install the strength member in the termination plate.
  • Page 5 Central core Fiber routing to the tray 6.1.3 Install the spiral tube of 200 mm on the cable. Fix the spiral tube with the foame on the basket. 6.2.1 Select a tube and strip the loose tube up to 200 mm from the outer cable jacket.
  • Page 6 6.2.3 Cut off the excess length of the transportation tube and secure 6.2.6 The tray can be blocked with the tray wedge. Turn the with tie wraps on the tray. wedge to the shown position. Fiber routing on the tray Single fiber 6.2.4 In case of central core route a transportation tube from the...
  • Page 7 Ribbon fiber 1 - 6xR12 7 - 12xR12 (X cut away) 6.3.3 Cut the appropriate number of plates. 13 - 18xR12 (X cut away) 19 - 24xR12 (X cut away) 6.3.4 Bend the remaining plates to the inside and click them into the slot.
  • Page 8 Installation of the gel block Remove the protection foil from the gel block and open the gel block. 6.3.6 Push the ribbon aligner into the spiral tube. Old termination plate with lockers Position the open gel block between the cables. Leave ±...
  • Page 9 New termination plate Slide the base over the Gel block and insert the frame into the base (check proper position). Position the open block between the cables. Grounding Insert the plugs in the unused ports. Remark: when installing the plugs be sure not to bend the crowns in the gel block.
  • Page 10 Place the O-ring back on a clean base. Slide the dome onto the base. Make sure that the arrows match. Use the clamp to seal dome and base. Close the clamp.
  • Page 12 © 2017 CommScope, Inc. All rights reserved. web at www.commscope.com FOSC and all trademarks identified by ® or ™ are registered trademarks or trademarks, respectively, of CommScope, Inc. For technical assistance, customer service, or to report any This document is for planning purposes only and is not intended to modify or supplement any specifications or warranties relating to missing/damaged parts, visit us at: CommScope products or services.
