H-8013
HANDHELD
INDUCTION SEALER
INCLUDED
Practice Seal
Practice Jar
and Cap
1.
Plug in and turn on using on/off switch on back
of unit. (See Figure 1)
Figure 1
2. Tightly screw on induction seal cap to jar and center
induction seal wand on top of cap. (See Figure 2)
NOTE: Compatible with 20-100 mm induction
seal caps.
Figure 2
Induction
Seal Cap
Jar
PAGE 1 OF 6
1-800-295-5510
uline.com
Replacement
Replacement
Start Button
Fuse
INSTRUCTIONS
On/Off
Switch
Pour le français, consulter les pages 5-6.
3. While applying slight downward pressure, press
and release the red start button and remove the
wand when the timer reaches zero. Cap will now be
sealed. (See Figure 3)
NOTE: Allow cap to cool before handling.
Figure 3
NOTE: Arrows on the left adjust time +/– 1
second and arrows on the right adjust +/– 0.1
second. (See Figure 3)
NOTE: Timer can be set between 0.1 and 9.9
seconds. To ensure best seal, unit should be
tested to determine the best time setting for
customer's product.
Para Español, vea páginas 3-4.
Start
Button
S
V
Timer
S
Arrows
0621 IH-8013

Advertisement

loading
Need help?

Need help?

Do you have a question about the H-8013 and is the answer not in the manual?

Questions and answers

Summary of Contents for U-Line H-8013

  • Page 1 Para Español, vea páginas 3-4. Pour le français, consulter les pages 5-6. H-8013 1-800-295-5510 uline.com HANDHELD INDUCTION SEALER INCLUDED Practice Seal Practice Jar Replacement Replacement and Cap Start Button Fuse INSTRUCTIONS Plug in and turn on using on/off switch on back 3.
  • Page 2: Troubleshooting

    REPAIR START BUTTON REPLACEMENT FUSE REPLACEMENT NOTE: Make sure unit is not connected to power. Using screwdriver, pop open fuse under plug. Remove top of sealer wand. (See Figure 4) (See Figure 5) 2. Remove wires and start Figure 4 button by unscrewing nut.
  • Page 3 H-8013 800-295-5510 uline.mx SELLADOR POR INDUCCIÓN PORTÁTIL INCLUYE Sello de Práctica Tapa y Repuesto de Fusible de Frasco de Botón de Inicio Repuesto Práctica INSTRUCCIONES Enchufe y encienda usando el interruptor de 3. Al presionar levemente, mantenga el botón rojo de encendido/apagado en la parte posterior de la inicio oprimido y retire la extensión de la selladora...
  • Page 4: Solución De Problemas

    REPARACIÓN REEMPLAZO DEL BOTÓN DE INICIO REEMPLAZO DEL FUSIBLE NOTA: Asegúrese de que la unidad no esté Usando un desarmador, conectada. saque el fusible que está debajo del enchufe. Retire la parte superior de la extensión de la (Vea Diagrama 5) selladora.
  • Page 5 H-8013 1-800-295-5510 uline.ca THERMOSCELLEUSE PAR INDUCTION MANUELLE INCLUS Sceau d'essai Récipient Bouton de Fusible de et opercule démarrage de rechange d'essai rechange INSTRUCTIONS Branchez et allumez l'appareil à l'aide de l'interrupteur 3. Tout en appliquant une légère pression vers le bas, marche/arrêt se trouvant à...
  • Page 6: Dépannage

    RÉPARATIONS REMPLACEMENT DU BOUTON DE DÉMARRAGE REMPLACEMENT DU FUSIBLE REMARQUE : Vérifiez que l'appareil n'est pas 1. Ouvrez le fusible sous la branché à une source d'alimentation. prise à l'aide d'un tournevis. (Voir Figure 5) Retirez le haut du Figure 4 manche de scellage.
