1. LED logo indicating the hub status
2. SmartBracket attachment panel (perforated part is required for actuating
the tamper in case of any attempt to dismantle the hub)
3. Socket for the power supply cable
4. Socket for the Ethernet cable
5. Slot for the micro-SIM
6. Slot for the micro-SIM
7. QR code
8. Tamper button
9. "On" button
LED indication
The Ajax logo on the hub front lights up red, white, or green depending on the
status of the power supply and Internet connection.
Event
At least two communication channels — Wi-Fi,
Ethernet, or SIM card — are connected
A single communication channel is connected
LED indicator
Lights up white
Lights up green
