- Page 1 AM 22 AUTO HTP POWER SPRAYER DISCLAIMER: DUE TO CONSTANT UPGRADATION, FEATURES AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE BEFORE OPERATING THIS MACHINE, PLEASE READ THESE INSTRUCTIONS CAREFULLY...
- Page 2 ATTENTION ! 1. Check every faster and make sure that the sprayer and the engine are installed firmly on the frame. 2. Set the two pulleys in a straight line and the belt in an appropriate tightness. 3. Check whether there is sufficient engine oil and use right fuel. 4.
-
Page 3: Troubleshooting
B. Open the ball cock to release the surplus air. C. Remove the water inlet cover to check if the valve asst' are stuck or damaged. TECHNICAL SPECIFICATION AM 22 AUTO HTP POWER SPRAYER Plunger diaxstroke 3 x 22 x 16 mm... - Page 4 DIAGRAM & SPARE PART OF AM 22 AUTO HTP POWER SPRAYER...
- Page 5 SPARE PART LIST OF AM 22 AUTO HTP POWER SPRAYER Part No. Description Q'ty AM 22 A-01 Crankcase AM 22 A-02 just-proof cap AM 22 A-03 pulley AM 22 A-04 set bolt AM 22 A-05 set bolt AM 22 A-06...
- Page 6 SPARE PART LIST OF AM 22 AUTO HTP POWER SPRAYER Part No. Description Q'ty AM 22 A-21 ceramic piston sleeve AM 22 A-22 double-end screw AM 22 A-23 o-ring AM 22 A-24 gasket AM 22 A-25 set bolt AM 22 A-26...
- Page 7 SPARE PART LIST OF AM 22 AUTO HTP POWER SPRAYER Part No. Description Q'ty AM 22 A-48 v-type o-ring AM 22 A-49 adjusting ring AM 22 A-50 set clip AM 22 A-51 suction chamber AM 22 A-52 suction chamber cap...
- Page 8 SPARE PART LIST OF AM 22 AUTO HTP POWER SPRAYER Part No. Description Q'ty AM 22 A-111 unloading valve cylinde AM 22 A-112 ball cock AM 22 A-113 screw,washer AM 22 A-114 o-ring(F.P.M) AM 22 A-115 auxiliary spring AM 22 A-116...
- Page 9 SPARE PART LIST OF AM 22 AUTO HTP POWER SPRAYER Part No. Description Q'ty AM 22 A-131 overflow chamber AM 22 A-132 screw,washer AM 22 A-133 compression packing AM 22 A-134 washer AM 22 A-135 set ring AM 22 A-136...
-
Page 10: Inspection And Maintenance
INSPECTION & MAINTENANCE For safety use, make sure the machine is cleaned every three-months. Before working, make sure to inspect the filter and the nozzle,and ensure there is no impurity. After working, make sure there is no water in the pump and the hose. If the machine needs to be repaired in the guarantee period, please return the machine to the shop. - Page 11 Warranty Card CUSTOMER COPY Purchaser’s Name & Address Date of Delivery Dealer’s Office Seal Product Name AM 22 AUTO HTP POWER SPRAYER Product Serial No. Dealer Sign Customer Sign. Invoice / DN No. I/We accept the terms and conditions of Warranty as in the Warranty Card.
- Page 12 1. LIMITED WARRANTY PERIOD : For a period of six months from the date of Sale / delivery of the product which ever is earlier. 2. LIMITED WARRANTY OBLIGATION : Replacement of defective part(s) by authorized dealer are free of charges. If found defective by reasons of defective material / poor workmanship, parts will be replaced and there will be no value re-imbursement.
- Page 13 1st Free Service Coupon ISO 9001-2015 CERTIFIED COMPANY FREE SERVICE COUPON (30 Days / 20 hrs (Which ever is earlier) Model Serial Number AM 22 AUTO HTP POWER SPRAYER PDI Date Service No. Purchase bill no. Date Dealer’s Office Seal & Signature Customer Signature.........
- Page 14 Small Maintenance. Big Savings. Small Maintenance. Big Savings. Small Maintenance. Big Savings.
- Page 15 Do’s Don’ts • Always read the instruction manual supplied along with the equipments and understand the correct installation and operating procedures before attempting to use the equipments. • It is important to use the personal protection equipments such as head helmet with visor, ear defenders, goggles, safety gloves, cut resistant shoes, trousers and jackets while operating potentially dangerous machines.
- Page 16 Agrimate Army For Pest Control ANY WHERE - ANY TIME - ANY CROP RATNAGIRI IMPEX PVT., LTD., Annapurna House, #1 / 1G, 7th Cross, New Guddadahalli Mysore Road, Bangalore - 560 026 Customer Care: 1800-425-3036 Email: info@ratnagiriimpex.com www.ratnagiriimpex.com AN ISO 9001:2015 CERTIFIED COMPANY...
