Summary of Contents for Agrimate AM-708-PRO-2S-WC
- Page 1 AM-708-PRO-2S -WC AM-708-PRO-2S-AC Motorised Knapsack Sprayer DISCLAIMER: DUE TO CONSTANT UPGRADATION, FEATURES AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE BEFORE OPERATING THIS MACHINE, PLEASE READ THESE INSTRUCTIONS CAREFULLY...
- Page 2 CAUTION 1. Stop running the gasoline engine before the tank is refueled, and ensure that the gasoline engine is far from the fire. Against the position, discharge the exhaust gas from the rooms, channels using gasoline engine or any other closed places. 2.
- Page 3 START UP 1. Turn on the gasoline switch until the gasoline flows out the clear plastic pipe. (Fig 3) 2. Close the choke totally (Fig 4) If the engine is heated, the choke must be totally opened. 3. Open half the throttle. 4.
-
Page 4: Maintenance
MAINTENANCE 1. Daily check • Check all screws and nuts • Check oil leakage or air leakage 2. Check after running 20 hours • Clean the core of the air cleaner • Clean the gasoline filter 3. Check after running 50 hours •... -
Page 5: Troubleshooting
TROUBLE SHOOTING 1. Fail to start • Oil switch is not turned on • Gasoline is mixed with water, replace it • The ignition plug has accumulated carbon or has been broken • Poor contact of the high voltage wire with the spark plug 2. - Page 6 AM-708-PRO-2S-WC ENGINE SPARE PARTS DIAGRAM SPRAYER AM-708-PRO-2S-AC...
- Page 7 PART NO. PART NAME AM708-PRO-E01 Screw AM708-PRO-E02 Cleaner Outside Cover AM708-PRO-E03 Filter Element AM708-PRO-E04 Screw Assy AM708-PRO-E05 Cleaner Inside Cover AM708-PRO-E06 Screw AM708-PRO-E07 Choke AM708-PRO-E08 Choke Handle AM708-PRO-E09 Carburetor AM708-PRO-E10 Gasket, Carburetor Side AM708-PRO-E11 Screw Assy AM708-PRO-E12 Inlet Mainfold AM708-PRO-E13 Washer, Cylinder Side AM708-PRO-E14 AM708-PRO-E15...
- Page 8 PART NO. PART NAME AM708-PRO-E29 Guide Plate AM708-PRO-E30 Gasket, Crankcase AM708-PRO-E31 Oil Seal AM708-PRO-E32 Ball-Bearing AM708-PRO-E33 AM708-PRO-E34 Crankshaft Comp. AM708-PRO-E35 Rear Half Crankcase AM708-PRO-E36 Starter Case AM 708 Only AM708-PRO-E36+37+38 Starter Pawl & Spring Assy AM 708 AM708-PRO-E36+37+38 Starter Pawl & Spring Assy AMP 768 AM708-PRO-E37 Starter Pawl Spring AM708-PRO-E38...
- Page 9 PART NO. PART NAME AM708-PRO-E55 Screw AM708-PRO-E56 Washer AM708-PRO-E57 Washer AM708-PRO-E58 Sealing Washer AM708-PRO-E59 Muffler AM708-PRO-E60 Bolt AM708-PRO-E61 Washer AM708-PRO-E62 AM708-PRO-E63 Cylinder AM708-PRO-E64 Gasket, Cylinder AM708-PRO-E65 Ring, Piston AM708-PRO-E66 Piston AM708-PRO-E66 Gasket, Fuel Tank Cap AM708-PRO-E67 Stop Ring AM708-PRO-E68 Pin, Piston AM708-PRO-E69 Needle, Bearing AM708-PRO-E70...
- Page 10 AM-708-PRO-2S-WC TANK & PUMP SPARE PARTS DIAGRAM OF SPRAYER AM-708-PRO-2S-AC...
- Page 11 AM-708-PRO-2S-WC TANK & PUMP SPARE PARTS LIST OF SPRAYER AM-708-PRO-2S-AC PART NO. PART NAME AM708-PRO-P01 Chemical Container AM708-PRO-P02 Filter AM708-PRO-P03 Gasket AM708-PRO-P04 Container Cover AM708-PRO-P05 Chain Holder AM708-PRO-P06 Strap AM708-PRO-P07 Gasket AM708-PRO-P08 Screw AM708-PRO-P09 Spring Washer AM708-PRO-P10 Screw AM708-PRO-P11 Washer...
- Page 12 PART NO. PART NAME AM708-PRO-P51 Bearing AM708-PRO-P52 O-Ring AM708-PRO-P53 Steel Pipe AM708-PRO-P54 Gasket AM708-PRO-P55 Drum Case AM708-PRO-P56 Drum Clutch AM708-PRO-P57 Bearing AM708-PRO-P58 Bearing AM708-PRO-P60 Gear Shaft and Gear AM708-PRO-P61 Bearing AM708-PRO-P62 O-Ring AM708-PRO-P63 Oil Inlet Cup AM708-PRO-P64 Crankcase Cover AM708-PRO-P64-1 O-Ring AM708-PRO-P66 O-Ring...
- Page 13 PART NO. PART NAME AM708-PRO-P82 Suction Chamber AM708-PRO-P83 Clip-L AM708-PRO-P83-1 Clip-S AM708-PRO-P84 Suction Hose AM708-PRO-P85 Outlet Chamber AM708-PRO-P86 Valve Seat AM708-PRO-P88 Pressure Valve AM708-PRO-P89 Pressure Valve Rod AM708-PRO-P90 Spring AM708-PRO-P93 Relief Valve Assy AM708-PRO-P94 AM708-PRO-P95 Pressure Valve Screw AM708-PRO-P96 Pressure Adjusting AM708-PRO-P97 Overflow Hose AM708-PRO-P99...
-
Page 14: Inspection And Maintenance
INSPECTION & MAINTENANCE For safety use, make sure the machine is cleaned every three-months. Before working, make sure to inspect the filter and the nozzle,and ensure there is no impurity. After working, make sure there is no water in the pump and the hose. If the machine needs to be repaired in the guarantee period, please return the machine to the shop. - Page 15 Warranty Card CUSTOMER COPY Purchaser’s Name & Address Date of Delivery Dealer’s Office Seal Product Name AM-708-PRO-2S -WC Motorised Knasack Sprayer AM-708-PRO-2S-AC Product Serial No. Dealer Sign Customer Sign. Invoice / DN No. I/We accept the terms and conditions of Warranty as in the Warranty Card.
- Page 16 1. LIMITED WARRANTY PERIOD : For a period of six months from the date of Sale / delivery of the product which ever is earlier. 2. LIMITED WARRANTY OBLIGATION : Replacement of defective part(s) by authorized dealer are free of charges. If found defective by reasons of defective material / poor workmanship, parts will be replaced and there will be no value re-imbursement.
- Page 17 1st Free Service Coupon ISO 9001-2015 CERTIFIED COMPANY FREE SERVICE COUPON (30 Days / 30 hrs (Which ever is earlier) Model Serial Number Motorised Knapsack Sprayers AM-708-PRO-2S-AC PDI Date Purchase bill no. Date Service No. Dealer’s Office Seal Dealer Signature..........Customer Signature.........
- Page 18 Small Maintenance. Big Savings. Small Maintenance. Big Savings. Small Maintenance. Big Savings.
- Page 19 Do’s Don’ts • Always read the instruction manual supplied along with the equipments and understand the correct installation and operating procedures before attempting to use the equipments. • It is important to use the personal protection equipments such as head helmet with visor, ear defenders, goggles, safety gloves, cut resistant shoes, trousers and jackets while operating potentially dangerous machines.
- Page 20 Agrimate Army For Pest Control ANY WHERE - ANY TIME - ANY CROP IMPORTED AND MARKETED BY RATNAGIRI IMPEX PVT LTD Annapurna House, #1/1G, 7th Cross, New Guddadahalli Mysore Road, Bangalore-560 026 Customer Care: 1800-425-3036 email: info@ratnagiriimpex.com www.ratnagiriimpex.com AN ISO 9001:2015 CERTIFIED COMPANY...
