Summary of Contents for Veeder-Root TLS-50
- Page 1 ● Manual No: 577013-892 Revision: A TLS-50 Console Quick Help...
- Page 2 Notice: This manual is a translation - the original manual is in English. Veeder-Root makes no warranty of any kind with regard to this publication, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
-
Page 3: System Options
Introduction TLS-50 Description The TLS-50 Tank Monitoring System monitors up to six in-tank probes for a wide variety of fluids. Probes are available to measure inventory only or inventory plus product temperature and/or water height. System status is available to the operator through a front panel display and remotely, via an optional RS-232 serial interface port (Figure 1). -
Page 4: System Security
- If Printer was selected in Communication Setup Type, the operator can print the Tank Status Report and Inventory Report, and Setup Report and Diagnostic Report (if enabled). Note, the Diagnostic Report is only for system troubleshooting and is not discussed in this manual. See the TLS-50 Site Prep Manual for a de- scription of this report. -
Page 5: Front Panel Controls
Front Panel Controls The components on the front panel of the TLS-50 are shown in Figure 2. In addition to the front panel red LED flashing when an alarm is activated, an audible beeper inside the console is also switched on. -
Page 6: Lcd Display
Introduction Front Panel Controls LCD DISPLAY The front panel Liquid Crystal Display (LCD) contains two lines. When the system is in the Top Level Menu, the top line of the display contains system status and/or alarm information. The bottom line contains Tank inventory information. -
Page 7: Tank Parameters
Introduction Display Messages Display Messages TANK PARAMETERS The following tank parameters are displayed one at a time as the operator scrolls through the Top Level Menu. • Product Volume, • Product Height, • Temperature Compensated Volume - (requires probes that have temperature measurement capability), •... -
Page 8: Printing Out Reports
Printing Out Reports With the TLS-50 Console Serial Package option you can print the reports described in this section on any printer that has a 9-pin dot matrix print head, a serial interface, and is capable of emulating Epson print commands. The report formats will fit on either letter size or A4 size paper. - Page 9 For technical support, sales or other assistance, please visit: www.veeder.com...
