- Page 1 OWNER S MANUAL ’ CHEST PRESS CAUTION Please read all instructions in this manual before use the equipment and keep the manual well.
- Page 4 Equipment Schematic right arm frame left arm frame Door Frame back pad set pad main stand frame...
-
Page 7: Assembly Step
Assembly step 1 Step Description Specifications Door Frame Inner Hexagon Socket Head Bolt M10*35 Spring washer Flat washer Φ20*Φ10.5*2 main stand frame ground connection frame cable 2 pulley φ114*25.8 socket cap screw M10*25 socket cap screw M10*35 socket cap screw M10*50 spring washer flat washer... - Page 8 Assembly step 2 Step Description Specifications left arm frame right arm frame cable 1 cable 2 bumping post 1 bumping post 2 Single hole square plate end cover φ59.5*φ11*14 decorative ring φ59.5*6 pulley cover 125*125*22*3 wide pulley φ116*47 pulley φ114*25.8 Cap socket screw M10*25 socket cap screw...
- Page 9 Assembly step 3 Step Description Specifications seat adjustment rack stop screw M10*18*φ8 Semi-sliding sleeve group socket cap screw M8*30 spring washer spring washer flat washer Φ16*Φ8.4*1.6 set pad back pad...
- Page 10 Assembly step 4 Step Description Specifications Guide rod Guide rod fixed plate Rubber bumper φ64*φ32*φ20*35 Rubber bumper φ38*φ21*10 Rod end cover Pulley sets φ89*32 Selector pin Inner Hexagon Socket Head Bolt M8*20 Inner Hexagon Socket Head Bolt M10*55 Spring washer Flat washer Φ16*Φ8.4*1.6 Flat washer...
- Page 11 Assembly step 5 Step Description Specifications Upper shield Shield fixed plate Fixed bushing Front shield Back shield M5*10 cross recessed countersunk head screw Countersunk head hexagon socket screw M6*16 Inner Hexagon Socket Head Bolt M6*16 Spring washer Flat washer Φ12*Φ6.4*1.6...
-
Page 12: Cable Routing Diagram
CABLE ROUTING DIAGRAM Correct Wrong Cable Cable limiting post limiting post... -
Page 13: Exploded View
Exploded View... - Page 14 Exploded List Description Specifications Doorframe Upper shield Shield fixed plate Guide rod Guide rod fixed plate Fixed bushing Front shield Back shield Rubber bumper φ64*φ32*φ20*35 Rubber bumper φ38*φ21*10 Floor cushion Rod end cover Pulley sets φ89*32 Selector pin cross recessed countersunk head screw M5*10 Countersunk head hexagon socket screw M6*16...
- Page 15 Exploded View...
- Page 16 Exploded List Description Specifications main stand frame ground connection frame left arm frame right arm frame seat adjustment rack back cushion adjustment rack cable 1 cable 2 Two hole connecting plate bumping post 1 bumping post 2 Single hole square plate aluminum end cover Φ6.5*Φ38*13 alumium ring...
- Page 17 Exploded List Description Specifications Cap socket screw M10*25 socket cap screw M10*25 socket cap screw M10*35 socket cap screw M10*50 socket cap screw M10*70 spring washer spring washer spring washer flat washer Φ12*Φ6.4*1.6 flat washer Φ16*Φ8.4*1.6 flat washer Φ20*Φ10.5*2 Rivet nut with small countersunk head M8*18 set pad back pad...
- Page 19 Weight stack label instructions 1 Wipe front surface of weight stack 2 Peel off back sheet adhesive side from label and make sure that the label remains attached to the application tape 3 Aline the center hole of label with the weight stack center hole 4 Line up the first label to hole on top plate 5 Make sure label is straight and slowly press into place...
- Page 21 PC2001...
