- Page 1 GLUTE KICK CAUTION Please read all instructions in this manual before use the equipment and keep the manual well.
- Page 4 Equipment Schematic Door Frame Cushion group Adjusting frame Petal rack Main frame...
-
Page 7: Assembly Step
Assembly step 1 Step Description Specifications Door Frame Inner Hexagon Socket Head Bolt M10*35 Spring washer Flat washer Φ20*Φ10.5*2 Connector Main frame Wire group 1 Pulley group Socket cap screw M10*35 Socket cap screw M10*50 Spring washer Flat washer Φ20*Φ10.5*2... - Page 8 Assembly step 2 Step Description Specifications Adjusting frame Drivepipe Spin axis 1 Gas spring sylinder Step rolling bearing Hexagon socket screw for umbrella head M10*25 Socket cap screw M8*30 Spring washer Spring washer Flat washer Φ16*Φ8.4*1.6 Flat washer Φ30*Φ10.5*2.5 Cushion group...
- Page 9 Assembly step 3 Step Description Specifications Guide rod Guide rod fixed plate Rubber bumper φ64*φ32*φ20*35 Rubber bumper φ38*φ21*10 Rod end cover Pulley sets φ89*32 Selector pin Inner Hexagon Socket Head Bolt M8*20 Inner Hexagon Socket Head Bolt M10*55 Spring washer Flat washer Φ16*Φ8.4*1.6 Flat washer...
- Page 10 Assembly step 4 Step Description Specifications Upper shield Shield fixed plate Fixed bushing Front shield Back shield cross recessed countersunk head screw M5*10 Countersunk head hexagon socket screw M6*16 Inner Hexagon Socket Head Bolt M6*16 Spring washer Flat washer Φ12*Φ6.4*1.6...
-
Page 11: Cable Routing Diagram
CABLE ROUTING DIAGRAM Wrong Correct Cable Cable limiting post limiting post... -
Page 12: Exploded View
Exploded View... - Page 13 Exploded List Description Specifications Doorframe Upper shield Shield fixed plate Guide rod Guide rod fixed plate Fixed bushing Front shield Back shield Rubber bumper φ64*φ32*φ20*35 Rubber bumper φ38*φ21*10 Floor cushion Rod end cover Pulley sets φ89*32 Selector pin cross recessed countersunk head screw M5*10 Countersunk head hexagon socket screw M6*16...
- Page 14 Exploded View...
- Page 15 Exploded List Description Specifications Connector Main frame Adjusting frame Petal rack Movable pulley bracket Breast pad frame Wire group 1 Wire group 2 Adjusting patch Drivepipe Spin axis 1 Spin axis 2 Sliding sleeve Sliding rack Guide rod Under fixing ring Aluminum end cap Aluiminu ring Aluminum baffle ring...
- Page 16 Exploded List Description Specifications Pipe 10 poundes counterweight component 10 poundes counterweight component 17 hole select pin Elastic cylindrical pin 10*45 Super linear bearing Step rolling bearing Circlip for hole d0=40 Inner hexagon end set screw M5*5 Cross countersunk head screw M5*10 Hexagon socket screw for umbrella head M8*25...
