- Page 1 OWNER S MANUAL ’ SEATED LEG PRE CAUTION Please read all instructions in this manual before use the equipment and keep the manual well.
- Page 4 Equipment Schematic Door Frame Foot Pedal Backrest Frame Sliding Frame Main Frame...
-
Page 7: Assembly Step
Assembly step 1 Step Description Specifications Doorframe Inner Hexagon Socket Head Bolt M10*35 Spring washer Flat washer Φ20*Φ10.5*2 Main Frame Connection Frame... - Page 8 Assembly step 2 Step Description Specifications Backrest Frame Foot Pedal Socket Head Inner Hexagon Bolt M8*30 Socket Head Inner Hexagon Bolt M8*75 Socket Head Inner Hexagon Bolt M10*20 Spring Washer Spring Washer Flat Washer Φ16*Φ8.4*1.6 Flat Washer Φ20*Φ10.5*2 Seat Pad Back Pad...
- Page 9 Assembly step 3 Step Description Specifications Guide rod Guide rod fixed plate Rubber bumper φ64*φ32*φ20*35 Rubber bumper φ38*φ21*10 Rod end cover Pulley sets φ89*32 Inner Hexagon Socket Head Bolt M8*20 Inner Hexagon Socket Head Bolt M10*55 Spring washer Flat washer Φ16*Φ8.4*1.6 Flat washer Φ20*Φ10.5*2...
- Page 10 Assembly step 4 Step Description Specifications Upper shield Shield fixed plate Front shield Back shield cross recessed countersunk head screw M5*10 Inner Hexagon Socket Head Bolt M6*16 Spring washer Flat washer Φ12*Φ6.4*1.6...
-
Page 11: Cable Routing Diagram
CABLE ROUTING DIAGRAM Wrong Correct Cable Cable limiting post limiting post... -
Page 12: Exploded View
Exploded View... - Page 13 Exploded List Description Specifications Doorframe Upper shield Shield fixed plate Guide rod Guide rod fixed plate Fixed bushing Front shield Back shield Rubber bumper φ64*φ32*φ20*35 Rubber bumper φ38*φ21*10 Floor cushion Rod end cover Pulley sets φ89*32 Selector pin cross recessed countersunk head screw M5*10 Countersunk head hexagon socket screw M6*16...
- Page 14 Exploded View...
- Page 15 Exploded List Description Specifications Main Frame Connection Frame Backrest Frame Sliding Frame Adjusting Frame Shroud Foot Pedal Cable Set Handle Adjustment Bracket 10-Pound Top Weight 20-Pound Weight 17-Hole Weight Selector Spring Pin 10*45 Guide Rod Thread Hole Fixed Collar Stop Screw Pop Pin Sleeve Spring...
- Page 16 Exploded List Description Specifications Socket Head Inner Hexagon Bolt Socket Head Inner Hexagon Bolt M6*20 Socket Head Inner Hexagon Bolt M6*50 Socket Head Inner Hexagon Bolt M8*30 Socket Head Inner Hexagon Bolt M8*75 Socket Head Inner Hexagon Bolt M10*20 Socket Head Inner Hexagon Bolt M10*35 Socket Head Inner Hexagon Bolt M10*50...
- Page 18 Weight stack label instructions 1 Wipe front surface of weight stack 2 Peel off back sheet adhesive side from label and make sure that the label remains attached to the application tape 3 Aline the center hole of label with the weight stack center hole 4 Line up the first label to hole on top plate 5 Make sure label is straight and slowly press into place...
