- Page 1 OWNER S MANUAL ’ DIP/CHIN ASSIST CAUTION Please read all instructions in this manual before use the equipment and keep the manual well.
- Page 5 Equipment Schematic Top Frame Door Frame Sliding Frame Leg Pad Pedal Frame...
-
Page 8: Assembly Step
Assembly step 1 Step Description Specifications Door Frame Inner Hexagon Socket Head Bolt M10*35 Spring washer Flat washer Φ20*Φ10.5*2 Main Frame Pedal Frame... - Page 9 Assembly step 2 Step Description Specifications Seat Pad Socket Head Inner Hexagon Bolt M8*30 Spring Washer Flat Washer φ16*φ8.4*1.6...
- Page 10 Assembly step 3 Step Description Specifications Left Parallel Bar Right Parallel Bar Socket Head Inner Hexagon Bolt M10*25 Socket Head Inner Hexagon Bolt M10*130 Socket Head Inner Hexagon Bolt M12*140 Spring Washer Flat Washer Φ20*Φ10.5*2 Top Frame...
- Page 11 Assembly step 4 Step Description Specifications Guide rod Guide rod fixed plate Rubber bumper φ64*φ32*φ20*35 Rubber bumper φ38*φ21*10 Rod end cover Selector pin Inner Hexagon Socket Head Bolt M8*20 Spring washer Flat washer Φ16*Φ8.4*1.6 Cable 10-Pound Weight 10-Pound Top Weight Assembly...
- Page 12 Assembly step 5 Step Description Specifications Upper shield Shield fixed plate Front shield Back shield cross recessed countersunk head screw M5*10 Inner Hexagon Socket Head Bolt M6*16 Spring washer Flat washer Φ12*Φ6.4*1.6...
-
Page 13: Cable Routing Diagram
CABLE ROUTING DIAGRAM Correct Wrong Cable Cable limiting post limiting post... -
Page 14: Exploded View
Exploded View... - Page 15 Exploded List Description Specifications Doorframe Upper shield Shield fixed plate Guide rod Guide rod fixed plate Fixed bushing Front shield Back shield Rubber bumper φ64*φ32*φ20*35 Rubber bumper φ38*φ21*10 Floor cushion Rod end cover Pulley sets φ89*32 Selector pin cross recessed countersunk head screw M5*10 Countersunk head hexagon socket screw M6*16...
- Page 16 Exploded View Description Specifications Main Frame Pedal Frame Left Parallel Bar Right Parallel Bar Sliding Frame Leg Pad Frame Pivot Bracket Pivot Rod 1 Pivot Rod 2 Sliding Guide Rod Thread Hole Fixed Collar Self-lubricating Bearing Stop Pin Handgrip Endcap Handgrip Collar Handgrip Endcap Handgrip Collar...
- Page 17 Exploded List Description Specifications Socket Head Inner Hexagon Bolt M8*30 Socket Head Inner Hexagon Bolt M10*25 Socket Head Inner Hexagon Bolt M10*35 Socket Head Inner Hexagon Bolt M10*50 Socket Head Inner Hexagon Bolt M10*75 Socket Head Inner Hexagon Bolt M10*130 Socket Head Inner Hexagon Bolt M12*140 Button Head Inner Hexagon Bolt...
- Page 19 Weight stack label instructions 1 Wipe front surface of weight stack 2 Peel off back sheet adhesive side from label and make sure that the label remains attached to the application tape 3 Aline the center hole of label with the weight stack center hole 4 Line up the first label to hole on top plate 5 Make sure label is straight and slowly press into place...
