ETENON Fitness PC1603 Owner's Manual

Pec deck
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER S MANUAL
'
Pec Deck
CAUTION
Please read all instructions in this manual before
use the equipment and keep the manual well.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC1603 and is the answer not in the manual?

Questions and answers

Related Manuals for ETENON Fitness PC1603

Summary of Contents for ETENON Fitness PC1603

  • Page 1 OWNER S MANUAL ’ Pec Deck CAUTION Please read all instructions in this manual before use the equipment and keep the manual well.
  • Page 3 Cautions In order to a void human injuri es and property dam age , before th e u e s of this series equipment please read the following mportant notices 1. Before u se o the e quipm ent please read this Owner’s Manual carefully The equipment should be assembled and used...
  • Page 4 equipment and can not increase he eight of weight stack by use of other manufacturers’ weight stack plate. (Apply to single station w h it ca 9. Child and pet are n lowed to be too lo c se to he equipment while t s in using 10.
  • Page 5 Equipment Schematic Right cam frame Left cam frame Upper frame Joint frame Upper shield Head cushion Right joint frame Left arm Right arm Chest pad Main frame Pulley cage Front shield Seat pad...

  • Page 6: Fitting Instructions

    Fitting instructions 1. When strip f the wrappage around the surface of equipment, should be a c reful do not hurt the ma chine with knife atches on the surface 2. When moving this equipment a suffi i c ent number of personnel should be used to prevent the equipment from collision or to avoid the injurie...

  • Page 7: Warranty

    force Make cer ain that he equipmen t is w ithout an ab normity before normally use the machine If something unu ual is found with the equip ment that , it is necessary to check the equipment carefully identify the probl s and reinstall it.

  • Page 8: Assembly Step1

    Assembly step1 Steps No. Description Specifications Qty Doorframe Hex socket head cap screw M12*30 Spring washer Plain washer Φ20*Φ10.5*2 Plain washer Φ24*Φ13*2.5 Main frame Left joint frame Right joint frame Hex socket head cap screw M10*30 Spring washer...

  • Page 9: Assembly Step2

    Assembly step2 Steps No. Description Specifications Qty Hex socket head cap screw M12*30 Spring washer Plain washer Φ24*Φ13*2.5 Main frame Upper frame...

  • Page 10: Assembly Step3

    Assembly step3 Steps No. Description Specifications Qty Upper frame Left cam frame Joint frame Axle Φ25*120 Steps rolling bearing Φ52*Φ25*18 Circlips for shaft d0=25...

  • Page 11: Assembly Step4

    Assembly step4 Steps No. Description Specifications Qty Upper frame Right cam frame Joint frame Axle Φ25*120 Steps rolling bearing Φ52*Φ25*18 Circlips for shaft d0=25...

  • Page 12: Assembly Step5

    Assembly step5 Steps No. Description Specifications Qty Joint frame Left arm Right arm Axle Φ25*120 Steps rolling bearing Φ52*Φ25*18 Circlips for shaft d0=25...

  • Page 13: Assembly Step6

    Assembly step6 Steps No. Description Specifications Qty Seat adjusting bracket Limiting screw Cable set 1 Cable set 2 Spring washer...

  • Page 14: Assembly Step7

    Assembly step7 Steps No. Description Specifications Qty Spring washer Plain washer Φ16*Φ8.4*1.6 Chest pad Head cushion Seat pad Hex socket head cap screw M8*35...
  • Page 15 Assembly step8 Steps No. Description Specifications Qty Doorframe Guild rod stator Guide rod Selector pin Rod end cover Rubber bumper Φ62*Φ20*26 Hex socket head cap screw M8*20 Spring washer Big washer Φ24*Φ8.4*2 Rubber bumper Φ38*Φ22*8 Cable set 1 10lb weight stack plate 10lb counterweight...
  • Page 16 Assembly step9 Steps No. Description Specifications Qty Doorframe Shield fixation column Upper shield Front shield Hex socket head cap screw M6*16 Hex socket head cap screw M8*20 Plain washer Φ12*Φ6.4*1.6 Plain washer Φ16*Φ8.4*1.6...

  • Page 18: Exploded View

    Exploded View...
  • Page 19 Exploded List Description Specifications Doorframe Guild rod stator Pulley catch Shield fixation column Shield fixation plate Guide rod Selector pin Upper shield Front shield Pulley Φ114*25.4 Rod end cover Rubber mat Rubber bumper Φ62*Φ20*26 Spring pin 10*45 Cross recess pan head self-tapping screw ST4.2*13 Hex socket head cap screw M6*16...
  • Page 20 Exploded List Specifications Pulley cage 19holes shaft Adjusting handle Axle Φ25*120 Fixed axle Φ8*44 Torsion spring Φ2*Φ11.5*30 Adjusting plunger Spring Φ1.4*Φ12.5*70 M20 nut Left adjustment sheet Right adjustment sheet Limiting screw Rotary knob End cover End ring Handle grip Φ31.5*Φ24*150 Handle grip Φ31.5*Φ24*110 Rubber bumper...
  • Page 21 Maintenance Attentions Daily Maintenance ( Basic Maintenance 1. Clean the seat pad b ck pad and cushion with warm w ater and soft cloth order to avoid the w at erosion t o the e s component 2. Clean the frame with warm water and soft cloth. 3.
