Item #0000 000 000
Model # C421100
USE AND CARE GUIDE
12 IN. WHITE LED STRIP KIT (4-PACK)
Questions, problems, missing parts? Before returning to the store,
call Commercial Electric Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in Commercial Electric through the purchase of this LED
strip kit. We strive to continually create quality products designed to enhance your home. Visit us online to see our
full line of products available for your home improvement needs. Thank you for choosing Commercial Electric!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Commercial Electric C421100
Summary of Contents for Commercial Electric C421100
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Commercial Electric through the purchase of this LED strip kit. We strive to continually create quality products designed to enhance your home. Visit us online to see our...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Installation ..............5 Safety Information .............2 Care & Cleaning ............11 Warranty..............3 Troubleshooting ............11 What is covered .............3 FCC Statement ............11 What is not covered ..........3 Pre-Installation ............3 Planning Installation ..........3 Safety Information Always keep the user manual within reach while CAUTION: Danger of eye damage. -
Page 3: Warranty
Warranty THREE (3) YEAR WARRANTY WHAT IS COVERED The manufacturer warrants this fixture to be free from defects in materials and workmanship for a period of three (3) years from date of purchase. This warranty applies only to the original consumer purchaser and only to products used in normal use and service. - Page 4 PACKAGE CONTENTS Part Description Quantity Adapter On/off switch (Assembled to the adapter (A)) 12 in. LED strip Y-connector wire Connector wire Connector wire...
-
Page 5: Installation
Installation Installation considerations □ What is the best layout configuration for your installation? □ How will you run and conceal the wires to your LED tape lighting? □ Temporarily mounting the LED light strip using painter’s tape allows you to experiment with tape light positioning before permanent installation. - Page 6 Installation Connecting LED tape and adapter □ Use the following four ways to connect the LED tape and adapter according to installation requirements. • Connect LED tape to connector • Connect connector to LED tape • Connect LED tape to LED tape •...
- Page 7 Installation (continued) Cutting the LED strip (optional) □ By cutting the strip and exposing the copper pads, optional connector (C760011) or accessory (C760110) pack can be used for a more custom installation. – – – Cut LED tape in center of copper pads Optional connector Optional accessory (C560011)
- Page 8 Installation (continued) Preparing the assembly location □ Power the LED tape lighting and temporarily hold or tape into position with painter’s tape or masking tape – do not remove the 3M paper backing. □ Adjust the lighting to various angles and positions to get the desired level of illumination and lighting appearance.
- Page 9 Installation (continued) Installing the LED strip □ 4A Tape method: Working from one end to the other, remove the 3M paper backing and press into place. Press between the LEDs to help ensure secure contact with the mounting surface. Avoid pressing on the individual LEDs as this could damage the LED solder connections.
- Page 10 Installation (continued) Connecting the power supply Connect adapter to power outlet On/off switch Adapter with plug LED strip light...
-
Page 11: Care & Cleaning
Care and Cleaning □ To clean the fixture, disconnect the power by unplugging the adapter. Use a dry or slightly dampened, clean cloth to wipe the exterior surface of the fixture. □ Do not use any cleaners with chemicals, harsh abrasives, or solvents. Use only a dry soft cloth to dust or wipe carefully. - Page 12 Questions, problems, missing parts? Before returning to the store, call Commercial Electric Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use.
