SKU #1012362057
Model #TAPE192RGB3K/HD
USE AND CARE GUIDE
16FT LED MULTI-COLOR SELECTABLE
TAPE LIGHT WITH REMOTE
Questions, problems, missing parts? Before returning to the store,
call Commercial Electric Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday,
9 a.m. - 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and con dence you have placed in Commercial Electric through the purchase of this product.
We strive to continually create quality products designed to enhance your home. Visit us online to see our full inventory
of products available for your home improvement needs. Thank you for choosing Commercial Electric!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Commercial Electric TAPE192RGB3K/HD
Summary of Contents for Commercial Electric TAPE192RGB3K/HD
- Page 1 THANK YOU We appreciate the trust and con dence you have placed in Commercial Electric through the purchase of this product. We strive to continually create quality products designed to enhance your home. Visit us online to see our full inventory...
-
Page 2: Table Of Contents
Connect the equipment into an outlet on a circuit different from that to which TAPE192RGB3K/HD the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. -
Page 3: Pre-Installation
Pre-Installation TOOLS REQUIRED (NOT INCLUDED) Measuring Scissors Tape HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Plug-in power adapter 16 feet LED flexible strip RF remote control Wire lead connector (optional use) Wire support clips AAA batteries HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance. -
Page 4: Installation
□ Use the wire lead connector (DD) to make turns and go around corners. Additionally, they can also be extended for gaps of any size with 5-pin Commercial Electric Accessory Kits (not Included). NOTE: Be sure all 24 V connections are secure and protected from electrical shorting. - Page 5 Installation (continued) Soldering the Led tape (optional) □ Soldering is another method for joining wires to the tape light and joining sections of tape light directly together. WARNING: Soldering tape lights to wire should only be performed by LED tape individuals with proper knowledge and experience in soldering.
- Page 6 Installation (continued) Direct wiring the power supply (optional) □ To direct wire, remove the AC input cable/plug and connect black live wire from a branch circuit to the line side (L) of the built-in terminal block and connect the white neutral wire to the neutral side of the terminal block (N), as indicated on the case. This LED power supply uses Class II AC inputs with a fully isolated case;...
-
Page 7: Operation
Operation Installing the Batteries Pairing Multiple Kits □ Remove the AAA batteries from the plastic wrap. The remote (CC) in each kit comes paired with the tape □ Press the clip to release the battery cover. light (BB). For larger installations, multiple kits can be □... -
Page 8: Care & Cleaning
Care and Cleaning □ To clean the light, use a clean dry or slightly damp cloth. □ Do not use cleaners with chemicals, solvents or harsh abrasives as damage to the light strip may occur. Troubleshooting Problem Possible Cause Solution The power adapter The LED strip Make sure the adapter is fully inserted into a live 120V outlet. - Page 9 Questions, problems, missing parts? Before returning to the store, call Commercial Electric Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use.
