Icom DC-197 Service Manual Addendum page 3

July 2016
SECTION 2.
[MAIN-A1/-A2/-A3/-A4/-A5/-A6 UNIT]
REF PARTS
DESCRIPTION
NO. NO.
IC1 1110006480 S.IC NJM2801U1-0543-TE1-#ZZZB
IC2 1110008640 S.IC MB3759PF-G-BND-JN-ERE1
IC3 1140014740 S.IC UPD789112AMC-550-5A4-A
IC4 1110002700 S.IC NJM2904M-TE1-#FMZB
Q1 1530004140 S.TRA L2SC4081RT1G
Q2 1550000090 S.FET RSQ035P03TR
Eqv. 1550000290 S.FET UPA1914TE-T1-AT
Eqv. 1550000330 S.FET FDC610PZ
Q3 1530004140 S.TRA L2SC4081RT1G
Q4 1530004140 S.TRA L2SC4081RT1G
Q6 1530004140 S.TRA L2SC4081RT1G
Q7 1590004070 S.TRA LDTC144EET1G
Q8 1510001151 S.TRA L2SA1576AST1G
Q9 1510001151 S.TRA L2SA1576AST1G
Q10 1590004070 S.TRA LDTC144EET1G
D1 1750001870 S.ZEN KDZ11V-Y-RTK/P
D2 1750001810 S.DIO L1SS400T1G
D3 1750001110 S.DIO SM240A-T
D4 1750001850 S.DIO LDAN222T1G
D5 1750001810 S.DIO L1SS400T1G
D6 1750001810 S.DIO L1SS400T1G
D7 1750001330 S.ZEN KDZ6.2V-Y RTK/P
X1 6060000790 S.CER CSTCR4M91G53-R0
L1 6200011490 S.COI SLF10145T-101M1R0-PF
L2 6200002611 S.COI NLV25T-R47J-PF
R2 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R3 7030003410 S.RES ERJ3GEYJ 561 V (560)
R4 7030003200 S.RES ERJ3GEYJ 100 V (10)
R5 7030009580 S.RES ERJ8RSJ R12V
R6 7030003600 S.RES ERJ3GEYJ 223 V (22K)
R7 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R8 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R9 7030003600 S.RES ERJ3GEYJ 223 V (22K)
R10 7030003800 S.RES ERJ3GEYJ 105 V (1M)
R11 7030003600 S.RES ERJ3GEYJ 223 V (22K)
R12 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R13 7030003600 S.RES ERJ3GEYJ 223 V (22K)
R14 7030003770 S.RES ERJ3GEYJ 564 V (560K)
R15 7030003650 S.RES ERJ3GEYJ 563 V (56K)
R16 7030003770 S.RES ERJ3GEYJ 564 V (560K)
R17 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R18 7030003410 S.RES ERJ3GEYJ 561 V (560)
R19 7030003620 S.RES ERJ3GEYJ 333 V (33K)
R20 7030003620 S.RES ERJ3GEYJ 333 V (33K)
R21 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R23 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R25 7030003320 S.RES ERJ3GEYJ 101 V (100)
R26 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R27 7030007220 S.RES ERA3YED 202V (2K)
R28 7030011200 S.RES ERA3YEB 303V (30K)
R29 7030011190 S.RES ERA3YEB 103V (10K)
R30 7030005871 S.RES ERA3YKD 104V (100K)
R31 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R32 7030005341 S.RES ERA3YED 332V (3.3K)
R33 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R34 7030003800 S.RES ERJ3GEYJ 105 V (1M)
R35 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R36 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R37 7030005501 S.RES ERA3YKD 124V (120K)
R38 7030005671 S.RES ERA3YKD 393V (39K)
R66 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R68 7030005321 S.RES ERA3YED 103V (10K)
R69 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R70 7030003800 S.RES ERJ3GEYJ 105 V (1M)
R71 7030003800 S.RES ERJ3GEYJ 105 V (1M)
R72 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R73 7030005981 S.RES ERA3YED 333V (33K)
R74 7030006091 S.RES ERA3YED 822V (8.2K)
R75 7030003500 S.RES ERJ3GEYJ 332 V (3.3K)
R76 7030003320 S.RES ERJ3GEYJ 101 V (100)
R77 7030003860 S.RES ERJ3GE JPW V
C1 4030006900 S.CER C1608 JB 1H 103K-T
C2 4030006900 S.CER C1608 JB 1H 103K-T
C3 4030006860 S.CER C1608 JB 1H 102K-T
C4 4030006900 S.CER C1608 JB 1H 103K-T
C5 4030006900 S.CER C1608 JB 1H 103K-T
C6 4510008540 S.ELE EEE1CA100SR
C7 4030011600 S.CER C1608 JB 1E 104K-T
C8 4030006900 S.CER C1608 JB 1H 103K-T
C9 4030011600 S.CER C1608 JB 1E 104K-T
C10 4510009150 S.ELE EEE1EA470WP
C11 4030006900 S.CER C1608 JB 1H 103K-T
C12 4030006900 S.CER C1608 JB 1H 103K-T
C13 4510009950 S.ELE EEEHC1C470P
C14 4510008660 S.ELE EEE0JA220SR
C15 4510008660 S.ELE EEE0JA220SR
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
(Amended page)
PARTS LIST
[MAIN-A1/-A2/-A3/-A4/-A5/-A6 UNIT]
H/V REF PARTS
M.
LOCATION NO. NO.
B 45.1/31.3 C16 4030006860 S.CER C1608 JB 1H 102K-T
B 60.9/32.5 C17 4030011600 S.CER C1608 JB 1E 104K-T
B 30.5/32.1 C18 4030006900 S.CER C1608 JB 1H 103K-T
B 17.2/29.0 C19 4030006900 S.CER C1608 JB 1H 103K-T
C20 4030009980 S.CER C1608 JB 1H 152K-T
C21 4030011600 S.CER C1608 JB 1E 104K-T
B 40.4/3.0 C22 4030006900 S.CER C1608 JB 1H 103K-T
B 35.7/2.7 C23 4030006900 S.CER C1608 JB 1H 103K-T
C24 4030006900 S.CER C1608 JB 1H 103K-T
C25 4030021600 S.CER C2012 JB 1H 104KT
B 57.0/25.3 C26 4030006900 S.CER C1608 JB 1H 103K-T
B 50.9/39.0 C27 4030006900 S.CER C1608 JB 1H 103K-T
B 48.4/20.5 C28 4030006900 S.CER C1608 JB 1H 103K-T
B 37.1/30.3 C29 4030011600 S.CER C1608 JB 1E 104K-T
B 24.9/20.1 C30 4030006900 S.CER C1608 JB 1H 103K-T
B 27.4/20.1 C31 4030019120 S.CER GRM188B31E105KA75D
B 21.2/20.0 C32 4030019120 S.CER GRM188B31E105KA75D
C33 4030011600 S.CER C1608 JB 1E 104K-T
C34 4030006900 S.CER C1608 JB 1H 103K-T
B 44.7/20.2 C35 4030006900 S.CER C1608 JB 1H 103K-T
B 39.1/5.8 C36 4510009150 S.ELE
B 35.6/8.2 C37 4510009950 S.ELE
B 30.1/24.1 C39 4030019230 S.CER C3225JB2A105KT
B 14.7/23.7 C41 4030006860 S.CER C1608 JB 1H 102K-T
B 31.9/23.8 C42 4030006860 S.CER C1608 JB 1H 102K-T
B 11.9/16.1 C44 4030006860 S.CER C1608 JB 1H 102K-T
B 22.9/32.6 J2 6510003391 CON
B 28.5/5.6 DS1 5040002740 LED
B 17.7/20.5
W1 8900019470 CAB
B 46.3/20.5
B 38.5/3.0
B 37.8/5.8 EP1 6910019900 S.BEA
B 9.2/11.4 EP2 6910014690 S.BEA
B 37.5/27.4 EP3 6910014690 S.BEA
B 59.0/25.3
B 49.0/39.1
B 60.2/39.1
B 52.8/39.1
B 52.3/35.8
B 62.8/39.1
B 53.5/35.8
B 54.7/35.8
B 54.7/30.5
B 53.5/30.5
B 52.3/30.5
B 65.4/25.3
B 39.9/27.4
B 38.7/27.4
B 38.7/31.2
B 12.2/23.7
B 23.5/27.7
B 15.3/34.2
B 22.3/24.0
B 21.1/24.0
B 24.7/24.0
B 16.6/34.2
B 21.1/27.7
B 11.0/23.7
B 11.0/20.1
B 19.2/34.2
B 17.9/34.2
B 39.9/31.2
B 39.9/34.0
B 37.5/34.0
B 25.7/38.1
B 17.2/17.4
B 19.6/17.4
B 22.8/20.1
B 29.3/20.1
B 19.6/20.1
B 16.0/23.7
B 13.4/20.1
B 13.4/23.7
B 22.3/27.7
B 18.4/17.4
B 54.8/3.9
B 13.3/11.4
B 53.6/3.9
B 12.1/11.4
B 10.9/11.4
B 46.6/24.6
B 41.9/29.7
B 41.9/32.9
B 48.7/29.7
B 48.8/10.9
B 43.9/10.5
B 10.0/5.0
B 18.6/3.8
B 52.4/24.6
B 56.5/39.7
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
1
DESCRIPTION M.
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
EEE1EA470WP B
EEEHC1C470P B
B
B
B
B
B3B-EH-S (LF)(SN)
RT3-03HRYG
OPC-2084
MPZ1608S601AT B
MPZ1608S221A-T B
MPZ1608S221A-T B
S.=Surface mount
H/V
LOCATION
61.5/39.1
53.5/33.1
54.7/33.1
61.5/25.3
64.1/25.3
36.1/23.8
34.8/23.8
14.0/34.2
23.5/24.0
13.5/27.3
9.8/23.7
12.2/20.1
38.7/34.0
32.2/39.8
33.4/39.8
42.7/10.5
11.4/5.0
15.8/20.1
14.6/20.1
28.1/17.4
48.8/3.8
18.6/10.9
40.0/9.5
27.1/25.8
22.8/38.1
10.4/16.4
35.6/12.6
56.2/2.4
56.2/5.4
