Icom DC-197 Service Manual Addendum page 6

INTRODUCTION
This service manual describes the latest technical information
for the BC-197 MULTI CHARGER, at the time of publication.
MODEL VERSION
OTH
USA
EUR
OTH-01
USA-01
EUR-01
OTH-02
USA-02
BC-197
EUR-02
OTH-03
USA-03
EUR-03
OTH-04
USA-04
EUR-04
ORDERING PARTS
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit Icom part number
2. Component name
3. Equipment model name and unit name
4. Quantity required
<ORDER EXAMPLE>
1110003491 S.IC
NJM2801U1
8820001210 Screw 2438 screw
Addresses are provided on the inside back cover for your
convenience.
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the
United Kingdom, Germany, France, Spain, Russia and/or other countries.
SUPPLIED INSTALLED
AC ADAPTOR ADAPTOR
–
BC-157S(USA)
AD-120
BC-157S(EUR)
–
BC-157S(USA) AD-121
BC-157S(EUR)
–
BC-157S(USA) AD-122
BC-157S(EUR)
–
BC-157S(USA) AD-124
BC-157S(EUR)
–
BC-157S(USA) AD-129
BC-157S(EUR)
BC-197 MAIN UNIT 5 pieces
BC-197 Top cover 10 pieces
CAUTION
NEVER connect the charger to an AC outlet or to a DC power
supply that uses more than the specifi ed voltage. This will
ruin the charger.
DO NOT expose the charger to rain, snow or liquids.
DO NOT reverse the polarities of the power supply when con-
necting the charger.
To upgrade quality, any electrical or mechanical parts
and internal circuits are subject to change without notice
or obligation.
REPAIR NOTES
1. Make sure that the problem is internal before dis-
assembling the charger.
2. D O N OT o p e n t h e c h a r g e r u n t i l t h e c h a r g e r i s
disconnected from the AC adaptor.
3. DO NOT force any of the variable components. Turn them
slowly and smoothly.
4. DO NOT short any circuits or electronic parts.
(BC-197+AD-129+BC-157)
