- Page 1 Ilumiline Inground Tri-12 IP Optic 25 RGB Quick Reference Guide...
-
Page 2: Safety Notes
Ilumiline Inground Tri-12 IP Optic 25 RGB QRG About This The Ilumiline Inground Tri-12 IP Optic 25 RGB Quick Reference Guide (QRG) only contains the product’s connection and mounting information, as Guide well as the menu options and DMX values. - Page 3 Ilumiline Inground Tri-12 IP Optic 25 RGB QRG · Features 1, 3, 4, 6, or 7 channel DMX-512 LED inground wash light · Operating modes: 1-channel: Dimmer 3-channel: RGB control 4-channel: Dimmer, RGB control 6-channel: RGB control per module (two modules)
-
Page 4: Power Wiring
Ilumiline Inground Tri-12 IP Optic 25 RGB QRG AC Power This product has an auto-ranging power supply that works with an input voltage range of 100~240 VAC, 50/60 Hz. Power Wiring You can connect the bare-ended IP67 rated power cable from the product to an IP67 rated power connector or use an IP67 rated junction box. - Page 5 Ilumiline Inground Tri-12 IP Optic 25 RGB QRG You can connect the bare-ended IP67 rated signal cable from this product to two IP67 rated signal connectors (DMX in and DMX Out) or use an IP67 Connection rated junction box. If using an IP67 rated junction box, make sure to use IP67 rated conduit.
- Page 6 Ilumiline Inground Tri-12 IP Optic 25 RGB QRG Ilumicon and The Ilumiline Inground Tri-12 IP Optic 25 RGB can operate with either an Ilumicon or a DMX controller. Use the standard DMX connection, as shown on page 4 (DMX Junction Box Wiring) to connect this product to any of Controllers those controllers.
-
Page 7: Installation
Ilumiline Inground Tri-12 IP Optic 25 RGB QRG Installation Before mounting this product, read the Safety Notes at the beginning of the Ilumiline Inground Tri-12 IP Optic 25 RGB User Manual and follow the mounting procedures. Installation Diagram Signal cable... -
Page 8: Ilumicode Control Panel Description
Ilumiline Inground Tri-12 IP Optic 25 RGB QRG Ilumicode Button Function Control Panel <POWER> Turns the Ilumicode unit on. Description <MENU> Scrolls through the main level or exits from the current menu or function. NOTE: Press and hold to turn the unit off. -
Page 9: Menu Options
Ilumiline Inground Tri-12 IP Optic 25 RGB QRG Menu Options Main Level Programming Levels Description Sets the DMX starting address 001~512 PERSON ARC1 3-channel: RGB control 4-channel: RGB control + dimmer ARC1+D ARC FULL 7-channel: RGB control + dimmer REMOTE... -
Page 10: Dmx Values
Ilumiline Inground Tri-12 IP Optic 25 RGB QRG DMX Values ARC FULL Channel Function Value Percent/Setting 000 ó 255 0~100% Dimmer 000 ó 255 0~100% (Step Time if CUS 01~10 active) 000 ó 255 0~100% (Fade Time if CUS 01~10 active) Green 000 ó... - Page 11 Ilumiline Inground Tri-12 IP Optic 25 RGB QRG ARC + D Channel Function Value Percent/Setting 000 ó 255 0~100% Dimmer 000 ó 255 0~100% 000 ó 255 0~100% Green 000 ó 255 0~100% Blue SOLID Channel Function Value Percent/Setting 000 ó 255 0~100%...
- Page 12 Ilumiline Inground Tri-12 IP Optic 25 RGB QRG USA WORLD HEADQUARTERS Contact General Information - ILUMINARC Technical Support Address: 5200 NW 108th Avenue Voice: (800) 762-1074 Sunrise, FL 33351 Email: support@iluminarc.com Voice: (954) 923-3680 Fax: (800) 544-4898 World Wide Web www.iluminarc.com...
