Summary of Contents for Iluminarc Ilumipanel 180

  • Page 1 Ilumipanel 180 IP Optic 15/30 RGBWA User Manual...
  • Page 2 Edition Notes Edition Notes The Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13 covers the description, safety precautions, installation, programming, operation, and maintenance of the Ilumipanel 180 IP Optic ® 15/30 RGBWA. ILUMINARC released this edition of the Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev.
  • Page 3: Table Of Contents

    ARC 1 + D ......................... 15 ARC 2 + D ......................... 16 ARC 3 ..........................16 ARC 3 + D ......................... 16 SOLID ..........................16 SPECIAL 1 ........................16 SPECIAL 2 ........................17 Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13...
  • Page 4 Troubleshooting Guide ....................19 Photometrics ......................20 LED Disclaimer ......................22 LED Life ..........................22 LED Binning........................22 Color Rendering Index (CRI) ..................... 22 Returns Procedure ..................... 23 Technical Specifications ..................... 24 Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13...
  • Page 5: Introduction

    A range of menu values from which to choose in a menu 1~10 A set of two mutually exclusive menu options in a menu Yes/No A unique value to enter or select in a menu Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13...
  • Page 6: Safety Notes

    Ilumipanel 180 · In case of a serious operating problem, stop using this product immediately! IP Optic 15/30 RGBWA may require service, please contact ILUMINARC ® Technical Support. Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13...
  • Page 7: Product Description

    Product Description 2. Product Description The Ilumipanel 180 IP Optic 15/30 RGBWA is a high intensity wash product used to light a variety of both indoor and outdoor applications The Ilumipanel 180 IP Optic 15/30 RGBWA consists of a steel base and two adjustable panels.
  • Page 8: Product Overview

    Product Description Product Overview 316 Stainless Steel Gland Nuts Locking Adjustment Plate Position Locking W-DMX Antenna Power In Gore™ Valve Signal In/Out Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13...
  • Page 9: Product Dimensions

    Product Description Product Dimensions Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13...
  • Page 10: Installation

    Always mount this product in any safe position while making sure there is adequate room for ventilation, configuration, and maintenance. Installation The Ilumipanel 180 IP Optic 15/30 RGBWA has twelve (12) mounting points on the ® base of the product to secure to almost any surface. ILUMINARC...
  • Page 11: Ac Power

    Operation AC Power Always connect the Ilumipanel The Ilumipanel 180 IP Optic 15/30 RGBWA has an auto-ranging power supply that works with 180 IP Optic an input voltage range of 100~240 VAC, 50/60 Hz. 15/30 RGBWA to a protected circuit with an...
  • Page 12: Dmx Linking

    The units must be linked using You may link the Ilumipanel 180 IP Optic 15/30 RGBWA to a DMX controller using a DMX cable in a standard DMX serial connection or W-DMX™. If using other DMX units compatible with the...
  • Page 13: Controllers

    Operation Controllers The products in the Ilumipanel 180 IP Optic 15/30 RGBWA can operate with a standard DMX controller, the ILUMICON controller, or the Ilumicode addresser. The sections below will show you how to connect these products to the corresponding controllers.
  • Page 14: Ilumicon

    The Ilumipanel 180 IP Optic 15/30 RGBWA can also work with the ILUMICON controller instead of a standard DMX controller. Please refer to the ILUMICON User Manual to learn how to use this controller with the Ilumipanel 180 IP Optic 15/30 RGBWA products. The following figure illustrates how to connect the ILUMICON The RDM2go, controller to the Ilumipanel 180 IP Optic 15/30 RGBWA.
  • Page 15: W-Dmx™ Calibration

    Operation W-DMX™ Calibration You can run the Ilumipanel 180 IP Optic 15/30 RGBWA without DMX cabling using the W- DMX™ option. This product can operate in W-DMX mode up to 300 m (900 feet) from the W- The Ilumicode DMX transmitter. For wireless operation, the W-DMX receiver in the Ilumipanel 180 IP Optic...
  • Page 16: Operation

    30 seconds of inactivity. Control Options You can set the Ilumipanel 180 IP Optic 15/30 RGBWA start address in the 001~512 DMX range. This allows for the control of up to 51 products in the 10-channel Special 1 personality.
  • Page 17: Static Colors

    Repeat steps 3 and 4 for the other RGB colors to obtain a white color. Repeat steps 2 to 5 for the other white colors. Reset to Factory Settings Go to SETTINGS > RESET. Select an option (YES/NO). Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13...
  • Page 18: Menu Map

    Maximum output, unbalanced white COLOR RGBTOW White output is as per CALIB > RGBTOW settings SETTINGS Output matches that of product’s previous versions Resets unit to factory default settings RESET NO/YES Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13...
  • Page 19: Dmx Values

    000 ó 255 0~100% Blue ARC 1 + D Channel Function Value Percent/Setting 000 ó 255 0~100% Dimmer 000 ó 255 0~100% 000 ó 255 0~100% Green 000 ó 255 0~100% Blue Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13...
  • Page 20: Arc 2 + D

    000 ó 255 0~100% Module 2Red 000 ó 255 0~100% Module 2Green 000 ó 255 0~100% Module 2Blue 000 ó 255 0~100% Module 2White 000 ó 255 0~100% Module 2Amber Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13...
  • Page 21: Special 2

    006 ó 255 Slow~Fast 000 ó 009 010 ó 069 Speed 1 (Fastest) 070 ó 129 Dimmer Speed Speed 2 130 ó 189 Speed 3 190 ó 255 Speed 4 (Slowest) Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13...
  • Page 22: Technical Information

    In most cases, opening the product’s housing will invalidate its warranty, unless there is a Troubleshooting Table, written indication to the contrary. contact ILUMINARC ® Technical Support. Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13...
  • Page 23: Troubleshooting Guide

    DMX signal problems Too many products Install an optically coupled DMX splitter after unit #32 or before Interference from AC wires Keep DMX cables separated from power cables or fluorescent/black lights Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13...
  • Page 24: Photometrics

    39.7 Beam (50%): 30.7% 459.9 21.1 21.7 Total: 70.5% 1,057 Photometics Pro 1.3.2 copyright 2003-2008 by jSolutions, Inc. Reported data calculated from manufacturer's data file, based on IES recommended methods. Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13...
  • Page 25 25.1 Beam (50%): 19.4% 1547.4 11.9 12.4 Total: 64.9% 5,168.4 Photometics Pro 1.3.2 copyright 2003-2008 by jSolutions, Inc. Reported data calculated from manufacturer's data file, based on IES recommended methods. Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13...
  • Page 26: Led Disclaimer

    CRIs as low as 25 still produce visually pleasing white light. Evaluate LED systems in person and, if possible, on-site when color fidelity or color appearance are important issues. Source: DOE publication: PNNL-SA-56891, January 2008 Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13...
  • Page 27: Returns Procedure

    Outside the U.S., United Kingdom, Ireland, Mexico, or Benelux contact the dealer of record. Follow their instructions to request support or to return a product. Visit our website for contact details. Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13...
  • Page 28: Technical Specifications

    Integrated Cooling 104° F (40° C) Enhancement™ I/O Connectors Connector Type Channel Range IP Gland Nut 1,3, 4, 5, 6, 7, 9, 10 Ordering Ilumipanel 180 IP Optic 15/30 RGBWA 13180004 Ilumipanel 180 IP Optic 15/30 RGBWA User Manual Rev. 13...
