- Page 1 User Manual ILUMI Model ID: ILUMIPODLL...
- Page 2 Edition Notes The Ilumipod LL User Manual includes a description, safety precautions, installation, programming, operation and maintenance instructions for the Ilumipod LL as of the release date of this edition. Trademarks ILUMINARC, the Iluminarc logo and Ilumipod LL are registered trademarks or trademarks of Chauvet &...
-
Page 3: Table Of Contents
Color Temperature Chart ..................Configuration (Static Mode) ..................Configuration (Settings) ................... Dimmer Speed ....................... 12 Color Calibration ......................12 Factory Reset......................... 12 5. Maintenance....................Product Maintenance ....................6. Technical Specifications................Returns ......................Contact Us......................Ilumipod LL User Manual Rev. 1... -
Page 4: Before You Begin
2. This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Page 1 of 16 Ilumipod LL User Manual Rev. 1... -
Page 5: Safety Notes
LEDs, contributing to shorter lifespans if always used at full intensity. The average LED lifespan is 40,000 to 50,000 hours. To extend LED lifespan, maintain proper ventilation around the product, and limit the overall intensity. Ilumipod LL User Manual Rev. 1 Page 2 of 16... -
Page 6: Introduction
2. Introduction Description The Ilumipod LL from Iluminarc fuses plug-and-play installation with precision optics to create seamless splashes of light and color. Bringing energy to any architectural project in any weather conditions, it has a sleek, low-profile form factor and four-in-one LED optics. The advanced RGBL color mixing unlocks true whites from crisp and cool tones to warm incandescent ambers, as well as raucous, saturated shades. -
Page 7: Product Dimensions
Introduction Product Dimensions 16.65 in 423 mm 14.37 in 365 mm 17.44 in 443 mm 15.43 in 392 mm 11.18 in 284 mm 8.5 in 216 mm Ilumipod LL User Manual Rev. 1 Page 4 of 16... -
Page 8: Setup
3. Setup AC Power The Ilumipod LL has an auto-ranging power supply, and it can work with an input voltage range of 100 to 240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 9: Remote Device Management (Rdm)
RDM2go 3. Data + 3. Data + (red clip) Beam-Shaping Filters The Ilumipod LL can be used with the medium, wide, very wide, or asymmetrical beam-shaping filters (sold separately). Beam-shaping filter Filter retainer ring Screws Follow the instructions below to install the optional filters: Detach the filter retainer ring by removing the screws attaching it to the fixture. -
Page 10: Mounting
When rigging the product onto a truss, use hardware of appropriate weight capacity. Procedure The Ilumipod LL comes with two adjustable brackets which can be secured directly to a mounting surface. Make sure the mounting surface and hardware are capable of supporting the weight of this product. Use at least one mounting point per product. -
Page 11: Operation
Operation 4. Operation RDM2go Control The Ilumipod LL requires an external controller, such as the RDM2go (from Chauvet Professional), to change its configuration. Menu Map Refer to the Ilumipod LL product page on www.iluminarc.com for the latest menu map. The Ilumicode section of the RDM2go (from Chauvet Professional) is required to access the full menu of options. -
Page 12: Configuration (Dmx)
000 255 0–100% ARC2 (4 Channels) Channel Function Value Percent/Setting 000 255 0–100% Green 000 255 0–100% Blue 000 255 0–100% Lime 000 255 0–100% Page 9 of 16 Ilumipod LL User Manual Rev. 1... -
Page 13: Arc2+D (5 Channels)
000 255 0–100% Red (Group 2) 000 255 0–100% Green (Group 2) 000 255 0–100% Blue (Group 2) 000 255 0–100% Lime (Group 2) 000 255 0–100% Ilumipod LL User Manual Rev. 1 Page 10 of 16... -
Page 14: Special2 (9 Channels)
070 085 3200–4000K linear transition 175 190 7000–8000K linear transition 4000K 8000K 085 100 4000–4500K linear transition 190 205 8000–10000K linear transition 4500K 205 255 100000K Page 11 of 16 Ilumipod LL User Manual Rev. 1... -
Page 15: Configuration (Static Mode)
Operation Configuration (Static Mode) To set the Ilumipod LL to operate in a static or strobing color without DMX: 1. Go to the STATIC main level. 2. Select the parameter to configure, from: • RED, • GREEN, • BLUE, •... -
Page 16: Maintenance
6. Softly drag any dirt or grime to the outside of the transparent surface. 7. Gently polish the transparent surfaces until they are free of haze and lint. Always dry the transparent surfaces carefully after cleaning them. Page 13 of 16 Ilumipod LL User Manual Rev. 1... -
Page 17: Technical Specifications
1, 3, 4, 4, 5, 8, or 9 channels Ordering Product Name Item Name Item Code UPC Number Ilumipod LL ILUMIPODLL 01631639 781462219871 UL 1598 CSA C22.2 No. 250 E115166 Ilumipod LL User Manual Rev. 1 Page 14 of 16... -
Page 18: Returns
Returns Returns Send the product prepaid, in the original box, and with the original packing and accessories. Iluminarc will not issue call tags. Call Iluminarc and request a Return Merchandise Authorization (RMA) number before shipping the product. Be prepared to provide the model number, serial number, and a brief description of the cause(s) for the return. -
Page 19: Contact Us
Visit the applicable website above to verify our contact information and instructions to request support. Outside the U.S., U.K., Ireland, Benelux, France, Germany, or Mexico, contact the dealer of record. Ilumipod LL User Manual Rev. 1 Page 16 of 16...
