- Page 1 MIDWAY CABINET Assembly Guide Midway cabinets For Internal Use: 50-WKIN00110_MIDWAY_CABINET_Assembly_Rev1.indd...
- Page 2 (Ensure that both of the end panels are cut square and accurately on the top edge.) Step 2. 11/16" Measure thickness (mm) of (18mm) board of midway cabinet. 3/4" (19mm) 13/16" (20mm) Step 3. Refer to the drilling measurements on the following page and drill holes 5/16"...
- Page 3 MIDWAY Panel Drilling Key: For board thickness: CABINET 11/16" use detail: 3/4" use detail: 13/16" use detail: (18mm) (19mm) (20mm) Assembly Guide SEE TABLE TO SUIT CUSTOMER KITCHEN PLAN SEE TABLE SEE TABLE Front 23/64" 23/64" (9mm) (9mm) 3/8" 3/8" (9.5mm) (9.5mm) 25/64"...
- Page 4 Guide Step 4. To adjust the width of the midway cabinet you will need to cut the top and bottom panels as well as both of the shelves. Only cut the shelves and panels at a single end to reduce the amount of cut edges that are not machined.
- Page 5 MIDWAY It is important to be as accurate CABINET as possible. Assembly Guide 23/64" 23/64" (9mm) (9mm) 3/8" 3/8" (9.5mm) (9.5mm) 25/64" 25/64" (10mm) (10mm) Back Panel 23/64" 23/64" (9mm) (9mm) 3/8" 3/8" (9.5mm) (9.5mm) 25/64" 25/64" (10mm) (10mm) Width of back is the same as the length of the shelves/top + bottom panel Step 6.
- Page 6 MIDWAY CABINET Assembly Guide Page 5 For Internal Use: 50-WKIN00110_MIDWAY_CABINET_Assembly_Rev1.indd...
- Page 7 MIDWAY CABINET Assembly Guide For Internal Use: 50-WKIN00110_MIDWAY_CABINET_Assembly_Rev1.indd Page 6...
