- Page 1 User Manual Grand Prix Model: ™ HP120 REV. 6/4/21 13655 Stowe Dr. Poway, CA 92064 P: (858) 679-1191 F: (858) 726-6005 www.mytee.com...
- Page 2 Congratulations on the purchase of your new Grand Prix™ Automotive Detailing Extractor. As technology continues to develop you can work confidently knowing that both Mytee and its employees are equally dedicated to developing with the industry and its advances. Like any other piece of machinery or technology, the Grand Prix™ also requires proper maintenance and care to keep the product working over extended use.
-
Page 3: Table Of Contents
Table of Contents Important Safety Information At a Glance 1.1 - Technical Specifications 1.2 - Included with the Grand Prix™ 1.3 - Grand Prix™ Front View 1.4 - Grand Prix™ Rear View Machine Operation 2.1 - Powering the Grand Prix™ 2.2 - Filling the Solution Tank 2.3 - Connecting the Hoses 2.4 - Operating the Grand Prix™... -
Page 4: Important Safety Information
When and if calling This machine must be grounded. If it should malfunction or Mytee for support, please have your Model and Serial Number break down, grounding provides a path of least resistance for available for faster assistance. - Page 5 Important Safety Information To reduce the risk of fire, electrical shock, or injury: may contain: chemicals, grease, oil, acid, alkalines, or other dangerous liquids. 1. Read all instructions before using equipment. 19. Do not leave operating unattended. 2. Use only as described in this manual. Use only manufactur- er’s recommended attachments.
-
Page 6: At A Glance
1 - At a Glance 1.1 - Technical Specifications Solution Tank 10 gallon capacity Recovery Tank 9 gallon capacity Single 3-stage low amp Vacuum Motor 100 CFM, 130” water lift 120 PSI diaphragm pump Pump 1.3 GPM 1,200W REAL HEAT™ system Heater 210º... -
Page 7: Grand Prix™ Front View
1 - At a Glance 1.3 - Grand Prix™ Front View 1. Clear recovery tank lid 6. Rear foam-filled wheels 2. Switch plate 7. Solution line quick connect 3. Solution tank lid 8. Vacuum hose Cuff-Lynx™ connection 4. Solution tank 9. -
Page 8: Grand Prix™ Rear View
1 - At a Glance 1.4 - Grand Prix™ Rear View 1. Rear recovery tank drain valve 3. Power cord 2. Rear body bracket screws... -
Page 9: Machine Operation
2 - Machine Operation 2.1 - Powering the Grand Prix™ 2.4 - Operating the Grand Prix™ Plug the power cord from the Grand Prix™ into a standard grounded wall outlet. The Grand Prix™ operates off a single, ♦ grounded 20 amp outlet. 2.2 - Filling the Solution Tank In order to avoid vapor locking the unit, the components should be switched on by following the procedure below after... -
Page 10: Emptying The Tanks
2 - Machine Operation 2.5 - Emptying the Tanks Empty the recovery tank via the drain valve on the rear of the machine. Make sure there is a bucket in place under the valve or the machine is in a position so the dirty water is drained safely. -
Page 11: Machine Maintenance
This filter should be checked after ♦ each use. 3.3 - System Maintainer Regular flushing of the solution system with Mytee System Maintainer keeps your extractor running efficiently by removing hard water scaling that builds up in the system. -
Page 12: Troubleshooting
Circuit breaker tripped in building. Reset breaker in building. turning on. Faulty switch or power cord. Contact a Mytee Service Center. Unclog the jet by removing and soaking in a vinegar Jet is clogged. and water solution. Scrub with a soft brush. Repeat if Poor solution flow. - Page 13 NOTES...
- Page 14 Mytee, LLC 13655 Stowe Dr. Poway, CA 92064 www.mytee.com © 2021 Mytee, LLC...
