Instructions for
Grand Prix
HP120
Please read before use.
Register your product
at http://www.mytee.
com/support/register
General Information p. 2
Features p. 5
Operation p. 6
Wiring Diagram p. 10
Notes p.11
™
13655 Stowe Dr., Poway, CA 92064
1
Model #
Serial #
Form # ADP-HP120
12-16
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mytee Grand Prix HP120
Summary of Contents for Mytee Grand Prix HP120
-
Page 1: Table Of Contents
Instructions for Grand Prix HP120 ™ Please read before use. Register your product at http://www.mytee. com/support/register General Information p. 2 Features p. 5 Model # Operation p. 6 Serial # Parts & Pricing p. 8 Wiring Diagram p. 10 Form # ADP-HP120 Notes p.11... -
Page 2: General Information
If damage is evident, save the shipping carton so that it can we at Mytee Products Inc. strive to keep you on the cutting edge with superior be inspected by the carrier that delivered it. Contact the carrier immediately to file a freight damage claim. -
Page 3: Operation
• Refer to relevant in-depth troubleshooting information in “Technical Support” section 14. Work away from cords to avoid damage. of Mytee website for specific pump type. http://www.mytee.com/support/. 15. Use a defoamer in your recovery tank. 16. To clean heavily soiled areas, repeat cleaning from different directions. - Page 4 Q: Does Mytee recommend a tool for the machine? A: A variety of tools can be used with the unit, including our 8390 wand, 8700 crevice tool, 8400 upholstery tool, and 8400DX Mytee Dry™ upholstery tool. Q: Where do I plug the machine in? A: The HP120 requires a 20 amp grounded circuit.
- Page 5 HP120 GRAND PRIX™ FEATURES HP120 GRAND PRIX™ FRONT HP120 GRAND PRIX™ BACK 1. Waist high controls 8. Push handle 2. 2” Male Cuff-Lynx™ 9. Bucket-high drain valve 3. Solution tank lid 10. Vacuum exhaust 4. Female quick disconnect 11. Vent guard 5.
- Page 6 HP120 GRAND PRIX™ OPERATION REPLACING CUFF-LYNX™ WITH HOSE CUFFS FILLING THE SOLUTION TANK Twist clock-wise to remove Cuff-Lynx™. Twist counter clock-wise to attach cuff to vac. hose. Lift lid to fill. For best results, fill with warm water (140° F). VACUUM &...
- Page 7 HP120 GRAND PRIX™ OPERATION VACUUM SWITCH HEATER SWITCH Release tool trigger. Turn on heater. Wait 8 – 10 minutes for unit Turn on vacuum motor and begin cleaning. For best results to pre-heat. Once heated, re-key upholstery tool until hot water make two dry passes to every wet pass.
-
Page 8: Parts & Pricing
HP120 GRAND PRIX™ PARTS & PRICING Part prices are subject to change. - Page 9 HP120 GRAND PRIX™ PARTS & PRICING...
-
Page 10: Wiring Diagram
HP120 GRAND PRIX™ WIRING DIAGRAM... -
Page 11: Notes
NOTES Mytee Products Inc. 13655 Stowe Dr. Poway, CA 92064 www.mytee.com © 2016 Mytee Products Inc. Printed in the U.S.A.
