사 양; Specification - SAMCHULLY SH Instruction Manual

6. 사 양
SH
사양 / Specification / 规格
내경
형식
Available I.D.
Type
可用内径
型式
[mm]
SH-10036 36.0
SH-13046 46.0
SH-15052 52.0
SH-17068 68.0
SH-18077 77.0
SH-19082 82.0
SH-21010 106.0
SH-25011 117.5
최대사용 유압력
형식
Max. Operating Pressure
Type
最大。操作压力
型式
[MPa(kgf/cm²)]
SH-10036 4.0(40.8)
SH-13046 4.0(40.8)
SH-15052 4.0(40.8)
SH-17068 4.0(40.8)
SH-18077 4.0(40.8)
SH-19082 4.0(40.8)
SH21010 4.0(40.8)
SH-25011 4.0(40.8)

6. Specification

직경 피스톤 스트로크
Cylinder Dia. Piston stroke
缸径 活塞行程
[mm] [mm]
105 12
135 15
156 22
170 25
185 25
185 25
215 30
255 23
최대회전속도
Max. r.p.m.
最大转速
[min (r.p.m.)]
-1
8000
7000
6200
5600
5000
4800
3500
3000
6. 技术参数
피스톤 추력
압축 / Push / 推
[kN(kgf)]
25.0(2549)
42.3(4285)
60.0(6118)
63.0(6531)
75.3(7632)
76.0(7715)
91.8(9357)
132(13390)
관성모멘트 중량
GD Weight
2
转动惯量 重量
[N·m (kgf·m²)] [kgf]
2
0.43(0.044) 8.4
0.20(0.021) 10.0
0.44(0.045) 14.0
0.65(0.067) 16.5
0.83(0.084) 18.0
0.95(0.097) 25.0
1.84(0.188) 37.0
1.90(0.193) 50.0
Piston Force
活塞队
인축 / Pull / 拉
[kN(kgf)]
24.0(2447)
38.1(3865)
56.0(5710)
59.8(6060)
69.6(7087)
70.0(7156)
87.8(8952)
121(12305)
총 드레인량
Total Leakage
总泄漏
[ℓ/min]
3.0
3.0
3.9
4.0
4.2
4.5
6.0
7.0
Instruction Manual
