Assembly of the Articulating Arm with Vertical Extension stand is complete.
UNITRON ®
73 Mall Drive, Commack, NY 11725 • 631-543-2000 • www.unitronusa.com
SYSTEM 274 STEREO MICROSCOPES
7. Insert drop post into 3
secure with knob screw.
8. Slide focus mount onto drop post and secure
with knob screw on the back of the focus
mount.
9. Secure the focus mount to the drop post by
threading the metal safety thumb screw into
the bottom of the drop post.
moveable arm and
rd
13
