- Page 1 ® N30 for NDI 12G-SDI/NDI Bi-Directional Converter USER MANUAL CO.,LTD. Changsha KILOVIEW Electronics...
-
Page 2: Legal Notices
Legal Notices Subject to the receiving of this document from Changsha Kiloview Electronics Co., Ltd.,(Hereinafter referred to “Kiloview”), the following terms are understood and agreed. Or else, please stop using this document. This document is copyright of Kiloview, all rights reserved. The document covers the proprietary information of the company. - Page 3 COTENTS 1 PRODUCT INTRODUCTION................................1.1 P ................................RODUCT EATURES ................................ 1.2 T ECHNICAL ARAMETERS 2 USER GUIDE....................................3 PACKING LIST AND INTERFACE DESCRIPTION..........................3.1 P ..................................ACKING ................................. 3.2 I NTERFACE ESCRIPTION ..................................3.3 L ED INDICATORS 4 INSTALLATION AND CONNECTION..............................4.1 C .................................
-
Page 4: Product Introduction
A tally system with a big tally light is built-in for indicating which camera is in program or preview. N30 supports wide DC input range from 5V to 18V which can be easily powered by USB, power bank or camera battery, or PoE. A threaded screw camera mount is equipped for camera mounting. - Page 5 Support Voice Intercom Support (not available in this version) Management type Web control Threaded Screw Standard 1/4” screw(6.5mm) Power Supply DC 5V-18V or POE Power consumption Working temperature -20℃~45℃ Dimension 100x80x24mm Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 6 NDI sources in the same network segment, and select the source to decode and output to the monitor. You can also decode and output by means of manually adding NDI sources across network segments or NDI sources from non-default group. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 7 Packing List and Interface Description 3.1 Packing List 3.2 Interface 1.TYPE-C expansion port 2.Tally 3.Working indicator 4.1000M Ethernet (PoE) 5.SDI output 6.SDI input 7.Audio port 8.TYPE-C power port 9.Small Tally light Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 8 N30 for NDI·USER MANUAL 10.Reset button Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
-
Page 9: Installation And Connection
Installation and connection Connect Video Signal Connect an SDI video cable from a video source (such as a camera) to the N30’s SDI input connector. The SDI output is connected to the display device via one SDI cable. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... - Page 10 You can also connect directly to the network port of the computer. Connect Audio Using a 3.5mm interface headset with a Microphone to connect to the device or connecting 3.5mm analog audio (Note: Voice intercom function not realized in this version). Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 11 After connecting the power adapter (DC 5V), the power light will be on and the device starts working. If your switch supports PoE, there is no need to connect to the power supply. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 12 For the first login or the first login after restoring the factory settings, you will need to agree to the “EULA” that pops up. Otherwise, the NDI stream service cannot be used normally. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 13 IP address, Gateway and DNS according to this LAN. Click “Network” to view the device Ethernet address configuration and Failsafe address The Failsafe address is the default management IP address. Generally, you do not need to make special settings. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 14 To set the IP manually, you need to enter a fixed IP to the encoder, and this IP address is fixed as long as the encoder does not restore factory settings, this method is more stable. Therefore, each method has its own advantages, and can be selected accordingly. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 15 This address can be changed manually (Usually no need to change), the default address is 192.168.1.168. Note: When accessing the device by Failsafe address, your computer must have an IP address in the same network segment. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 16 N30 for NDI·USER MANUAL NDI discovery and monitor N30 for NDI converter is a professional video encoding/decoding device for NDI video production. It can convert SDI video source into NDI stream and transmit video through Ethernet for any compatible systems, devices or software in the network.
- Page 17 Note: After opening the selected video of the converter by Studio Monitor, click in the lower right corner of the player to open the Webpage of the converter directly, which is convenient for the management of the converter. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 18 NDI stream may not be automatically discovered NDI stream. 6.3 NDI Encode Bitrate The N30 device transmission requires high bit rate, so the device needs to be connected to a Gigabit network. The pulling stream device also needs a Gigabit network. Otherwise, the stream play will be abnormal or not smooth.
- Page 19 NDI channel name: When there are multiple NDI sources in the same network, as the default channel names are the same, so it’s required to modify the channel name with different parameters to identify each device correctly. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 20 The device supports PTZ control, both protocol types of PTZ over Ethernet and serial port are supported. PTZ over Ethernet needs to correctly configure the protocol address and port of the connected PTZ, and specify the PTZ control protocol (Sony Visca, Pelco-D/P supported). Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 21 USB to RS232/RS422/RS485 adaptor, the device supports PTZ control over serial port. After configuring the control parameters correctly, PTZ control service can be realized by PTZ control panel of NewTek Studio Monitor (Note: It is not available in this version) Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 22 NDI stream for discovery, and the channel name is “Decoding Channel”. Using Studio Monitor to connect the NDI stream and click the gear button in the lower right corner to go to the WEB page. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 23 "Group" box, and then click "OK" (no need to fill in the IP address), the device will search for the NDI sources of these two group names at the same time. (You are allowed to add multiple group names to search) Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 24 There is a blank output box in decoding preset, if switching to a source without video output, the device will output the set color. It can also be used for testing the output to the monitor by choosing different color. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 25 If the current decoding source is disconnected, a warming notice will be displayed at the up-right corner showing the device is offline. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
-
Page 26: System Settings
It takes about 3 seconds and current coding service will be interrupted. 9.3 Reboot “Reboot” is used to restart device software, which means restart the device. The processing takes about one minute. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... - Page 27 If you need help, please contact our technical support to complete the upgrade. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 28 WEB page to confirm whether the current software version and the latest upgrade package are the same, to make ensure the device upgrading is successful. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 29 Thank you for reading! Changsha KILOVIEW Electronics CO.,LTD. Tel: 86-731-88315979 Website: en.kiloview.com Technical support Email: support@kiloview.com Skype: kiloview-support/keqiu wang WhatsApp: +86-18573195156/18573195256 Address: 188#, Middle Huanbao Rd, Yuhua District, Changsha, Hunan Province, China Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
