N5/N6 Converter
NDI High Bandwidth+NDI|HX
Full Functional Codec
(Version 2023-2)
Contents
◼ Packing List
◼ Device interfaces and functions
◼ Device connection, login and use guide
◼ Device upgrade and restore to factory settings
Before using this product, it is recommended that you read the guide carefully. To ensure your personal safety and avoid physical or
electrical damage to the device, please strictly follow the instructions of this guide to install and use it under the guidance of
professionals. Incorrect electrical connections or physical installation may cause permanent damage to the device and even threaten
personal safety.
Leading solution provider of IP-Based video transmission
Quick Start Guide
Advertisement
Related Manuals for Kiloview N5
Summary of Contents for Kiloview N5
- Page 1 Leading solution provider of IP-Based video transmission Quick Start Guide N5/N6 Converter NDI High Bandwidth+NDI|HX Full Functional Codec (Version 2023-2) Contents ◼ Packing List ◼ Device interfaces and functions ◼ Device connection, login and use guide ◼ Device upgrade and restore to factory settings Before using this product, it is recommended that you read the guide carefully.
- Page 2 (5) Quick Start Guide ×1 2 Device Interface The following is the interface diagram of N6 as example: Type-C Extension Interface HDMI IN （Note: SDI IN for N5） Touch Screen（Left/Page up） HDMI OUT（Note: SDI OUT for N5） LCD Screen LINE IN/OUT (10) Power Port Touch Screen（Right/Page down）...
- Page 3 Tally/LCD Screen Red Light Note When N5/N6 is in encoding mode, after receiving the tally signal from NDI, the LCD display will show that the current video is in PGM or PVW state (red or green). 4 Application Scenario Note The following example diagrams all take N6 as an example, and N5 is the SDI interface input.
- Page 4 4.1 Encoding Mode HDMI Input LOOP Power Adapter Internet Switcher Encoding mode application system connection diagram 4.2 Decoding Mode HDMI Monitor Power Adapter NDI Source Switcher Decoding mode application system connection diagram...
- Page 5 “OK”， you can enter the current display module, view detailed information, modify basic configuration parameters or modify the working mode of N5/N6, etc. For more detailed operation steps, please refer to the user manual. Take N6 as an example：...
- Page 6 Download Kiloview Multiview for free Visit the website https://www.kiloview.com/en/ndi/multiview, click the [Get it Now] to install the software step by step. Kiloview Multiview is a free software for NDI video discovery, management and multi-view, which is popular and highly praised all over the world.
- Page 7 Step 2: Find the device in the discovery list and enter to the device web page through browser Introduction N5/N6 naming rules：N5/N6-<serial number>. Serial number refers to the numbers on the device label. Two ways of accessing to the device web page: ...
- Page 8 the discovery list). 7 Login to the device Web page Enter to the web page of the N5/N6 and both the username and the password are “admin” by default Note To ensure information security, it is recommended to change your password immediately after your first login.
- Page 9 Sources can be added to the Preset list by clicking "+" on the right of the NDI source. N5/N6 supports up to 9 Presets, and you can save the frequently used NDI sources in the Preset list, which could ensure you quickly select Presets 1-9 at any time to decode and output.
- Page 10 Step 1: Prepare a USB flash drive, copy the firmware file downloaded from Kiloview website to the USB flash drive. Step 2: Insert the USB flash drive into the N5/N6, after the device is turned on (about 2s), wait for the Kiloview logo to appear on the screen, long press and hold for more than 10s until the device enters recovery mode.
- Page 11 Step 4: During the upgrading, it will prompt with "Updating! Please keep the power on." (Please do not power off) Step 5: When the N5/N6 screen displays "Firmware updated successfully", the N5/N6 has completed the firmware upgrade. At this time, any operation of the scroll wheel will help you return to “RECOVERY”, please select “Reboot”...
- Page 12 2) When the device cannot log in to the web management page normally, the device can be restored to the default settings by operating the touch button on the front of the N5/N6. Note: After restoring factory setting, below parameters will be turned to default value: Login username and password will be “admin”.
