5.3.2.1 SFP+ and HD Mini-SAS Cable Configuration

This configuration includes the use of up to four SFP+ and two HD Mini-SAS cables installed into a CMA

arm.

Figure 53: Service Loop Dimension Figure

Table 16: Service Loop Dimension Table

5.3.3 Cable Configuration for CMA Lite

5.3.3.1 Maximum HD Mini-SAS Configuration

This configuration includes the use of up to two HD Mini-SAS cables, two Ethernet cables, and two power

cables installed into a CMA Lite arm.

6in.

5.3 Cabling for CMA Standard and CMA Lite

12in.

5. Installation

16in.
