Chapter 15
path regardless of other considerations. Normal internet usage does not require this
setting to be configured.
I want to:
Visit multiple networks and multiple servers at the same time.
For example, in a small office, my PC can surf the internet, but I also want to visit my
company's server. Now I have a switch and another router. I connect the devices as
shown in the following figure so that the physical connection between my PC and my
company's server is achieved. To surf the internet and visit my company's network at
the same time, I need to configure the static routing.
How can I do that?
1. Make sure the routers use different LAN IP addresses on the same subnet. Disable
Router 2's DHCP function.
2. Visit http://tplinkmodem.net, and log in with your TP-Link ID and the password you
set for the router.
3. Go to Advanced
click Save.
4. Click Add to add a new static routing entry. Finish the settings according to the
following explanations:
Modem router
WIFI WPS�Reset USB LAN1 LAN2 LAN3 LAN4�WAN DSL
LAN: 192.168.1.1
192.168.1.100
> Network > Static Routing. Select your current
Specify Your Network Settings
Router 2 Company's server
WAN: 172.30.30.100
WIFI WPS�Reset USB LAN1 LAN2 LAN3 LAN4�WAN DSL
LAN: 192.168.1.2
Switch
My PC
172.30.30.1
WAN Interface and
