TP-Link VR400 Quick Installation Manual

Quick Installation Guide
Wireless VDSL/ADSL Modem Router
* Images may differ from actual products.
2. Configure the Modem Router
You'll usually need an internet service username and password, given to you by your internet service provider (ISP) when you first signed up with them. If you are unsure, please check with your ISP.
Method 1: Via a Web Browser
1. Connect your device to the router (wired or wireless).
Wired
Turn off the Wi-Fi on your computer and connect it to the router via an Ethernet cable.
Wireless
A. Find the product label at the bottom of the
router.
B. Use the default network names (SSIDs) and
password to join the network.
Tip: If you are using a smartphone or tablet, you can also
scan the QR code to join the preset 2.4 GHz network directly.
1. Connect the Hardware
Phone Jack
Phone (Optional)
If you don't need the phone service, just directly connect the modem router to the phone jack with the provided phone cable.
2. Launch a web browser and type in http://tplinkmodem.net or 192.168.1.1. Create a
password and get started.
Note: If the login page does not appear, please refer to Q1 of Need Help? in this guide.
http://tplinkmodem.net
3. Follow the step-by-step instructions to set up an internet connection and register
the TP-Link Cloud service.
QR
Code
Enjoy the internet!
Power Adapter
Phone Cable
1
Power
DSL Splitter
PHONE MODEM
Phone Cable
New Password
Low Middle High
Confirm Password
Let's Get Started
3
Verify that the following LEDs turn stable
before continuing with the configuration.
POWER DSL
WPS�Reset USB LAN1 LAN2 LAN3 LAN4�WAN
2
Modem Router
Notes:
1. The DSL LED
stabilize.
2. If the DSL LED does not turn on, please refer to
Q2 of Need Help? in this guide.
Method 2: Via TP-Link Tether App
1. Download the TP-Link Tether app.
or
Scan for Tether
2. Open the Tether app and log in with your TP-Link ID.
Note: If you don't have an account, create one first.
3. Tap the button in the Tether app and select Router > DSL Modem Router.
Follow the steps to complete the setup and connect to the internet.
Enjoy the internet!
DSL
Power DSL Wi-Fi
On On On
takes about 1 to 2 minutes to
Tether
