Ports and Antennas

The modem router's back panel shows the connection ports, buttons and antennas.
Refer to the following for detailed instructions.
Item
Power Port
WiFi Button
WPS/Reset Button
USB Port
LAN1, LAN2, LAN3,
and LAN4/WAN
Ports
DSL Port
Antennas
For connecting the modem router to power socket via the provided
power adapter.
Press to turn Wi-Fi on or off.
Press for 1 second to start a WPS synchronization.
Press and hold for at least 5 seconds until all LEDs turn on momentarily
to reset the modem router to factory default settings
For connecting to USB
For connecting to your PCs or other Ethernet network devices.
In wireless router mode, the LAN4/WAN port is used for connecting to
a Cable/FTTH/VDSL/ADSL device.
For connecting the modem router to the Internet. Connect the port to
the splitter or directly connect the port to the phone jack via a phone
cable. For details, please refer to
Used for wireless operation and data transmission.
Description
modems.
Connect Your Modem
.
Router.
